Standards | IEEE 802.3 10Base-T, IEEE802.3u 100Base-TX |
---|---|
Copper ports | 24x 10/100/1000 Mbps RJ-45 |
Free slots | 4x 1000 Mbps SFP |
Additional ports | 1× RJ45 Console Port, 1× Micro-USB Console Port |
PoE+ Ports(RJ45) | Standard 802.3at/af compliant, PoE+ Ports 24 Ports, up to 30 W per port, Power Budget 384 W |
Auto MDI/MDI-X | yes |
Auto-negotiation (Nway) | yes |
Software features | |
Quality of Service | Support 802.1p CoS/DSCP priority, Support 4 priority queues, Queue scheduling- SP, WRR, SP+WRR, Port/Flow- based Rate Limiting |
L2 and L2+ Features | DHCP Relay, DHCP VLAN Relay, DHCP L2 Relay, Link Aggregation, Static link aggregation, 802.3ad LACP, Up to 8 aggregation groups and up to 8 ports per group, Spanning Tree Protocol, 802.1D STP, 802.1w RSTP, 802.1s MSTP, STP Security TC Protect, BPDU Filter/Protect, Root Protect, Loopback Detection, Flow Control, 802.3x Flow Control, Mirroring, Port Mirroring, CPU Mirroring, One-to-One, Many-to-One, Flow-Based, Ingress/Egress/Both, Device Link Detect Protocol (DLDP), 802.1ab LLDP/ LLDP-MED |
L2 Multicast | 511 IPv4, IPv6 shared multicast groups, IGMP Snooping, IGMP v1/v2/v3 Snooping, Fast Leave, IGMP Snooping Querier, Static Group Config, Multicast VLAN Registration (MVR), Multicast Filtering, MLD Snooping, MLD v1/v2 Snooping, Fast Leave, MLD Snooping Querier, Static Group Config, Limited IP Multicast (256 profiles and 16 entries per profile) |
IPv6 Support | IPv6 Dual IPv4/IPv6, Multicast Listener Discovery (MLD) Snooping, IPv6 neighbor discovery (ND), Path maximum transmission unit (MTU) discovery, Internet Control Message Protocol (ICMP) version 6, TCPv6/UDPv6, IPv6 applications, DHCPv6 Client, Ping6, Tracert6, Telnet (v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP |
VLAN | VLAN Group, Max. 4K VLAN Groups, 802.1Q tag VLAN, MAC VLAN, Protocol VLAN, GVRP, Voice VLAN |
Security | AAA, 802.1X, Port based authentication, MAC (Host) based authentication, Authentication Method includes PAP/EAP-MD5, MAB, Guest VLAN, Support Radius authentication and accountability, IP/IPv6-MAC Binding, 512 Binding Entries, DHCP Snooping, DHCPv6 Snooping, ARP Inspection, ND Detection, IP Source Guard, 253 Entries, Source IP+Source MAC, IPv6 Source Guard, 183 Entries, Source IPv6 Address+Source MAC, DoS Defend, Static/Dynamic/Permanent Port Security, Up to 64 MAC addresses per port, Broadcast/Multicast/Unicast Storm Control, kbps/ratio control mode, Port Isolation, Secure web management through HTTPS with SSLv3/TLS 1.2, Secure Command Line Interface (CLI) management with SSHv1/SSHv2, IP/Port/MAC based access control |
Management | |
Omada App | Yes |
Centralized Management | Omada Cloud-Based Controller, Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller |
Cloud Access | Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
Management Features | Web-based GUI, Command Line Interface (CLI) through telnet, SNMPv1/v2c/v3, SNMP Trap/Inform, RMON (1,2,3,9 groups), SDM Template, DHCP/BOOTP Client, Dual Image, Dual Configuration, CPU Monitoring, Cable Diagnostics, EEE, SNTP, System Log |
Switching capacity [Gbps] | 56 |
Packet Forwarding Rate | 41.66 Mpps |
MAC Address Table | 16K |
Jumbo Frame | 9 KB |
Housing / case type | Rack Mountable |
Dimensions | 17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm) |
Fan Quantity | 2 |
Operating temperature | 0°C ÷ 45°C |
Operating humidity | 10% ÷ 90%, non-condensing |
Power | internal, 100~230VAC 50/60Hz |
Max Power Consumption | 31.0 W (110 V/60 Hz) (no PD connected), 463.8 W (110 V/60 Hz) (with 384 W PD connected) |
Max Heat Dissipation | 105.78 BTU/h (110 V/60 Hz) (no PD connected), 1582.49 BTU/h (110 V/60 Hz) (with 384 W PD connected) |
Certificates | CE, FCC, RoHS |
Warranty period | 5 years |
Manufacturer | TP-Link |
Net Price: 321,00 EUR Unit: pcs
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
