Standards | IEEE 802.3/x |
---|---|
Copper ports | 8x 10/100/1000 Mbps RJ-45 (PoE), 2× 1000 Mbps RJ45 Ports |
PoE Ports | RJ45, Standard Compliant with 802.3 af/at Powered Devices, PoE Ports Port 1- Port 8 |
PoE Power Budget | 110 W |
Advanced Features | Compatible With IEEE 802.3af/at Compliant PDs, Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission), Priority Mode Button (Ports 1–2), Isolation Mode Button (Ports 1–4 / 5-8), PoE Auto Recovery (Ports 1-8), MAC Address Auto-Learning and Auto-Aging, IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode |
Auto MDI/MDI-X | yes |
Auto-negotiation (Nway) | yes |
Switching architecture / speed | Store and Forward |
Data Rates | 10/100Mbps at half duplex, 20/200Mbps at full duplex |
Switching Capacity | 20 Gbps |
Mac Address Table | 4K |
Jumbo Frame | 16 KB |
Dimensions | 209 × 126 × 26 mm (8,2 × 4,9 × 1,0 in) |
Operating temperature | 0°C ÷ 40°C |
Storage Temperature | -40°C ÷ 70°C |
Operating humidity | 10% ÷ 90%, non-condensing |
External Power Supply | External Power Adapter (Output 54VDC / 2.22A) |
Max Power Consumption | 7.37 W (220V / 50Hz with no PD connected), 129.4 W (220V / 50Hz with 111 W PD connected) |
Max Heat Dissipation | 25.13 BTU/h (220V / 50Hz with no PD connected), 441.25 BTU/h (220V / 50Hz with 111 W PD connected) |
Net Price: 43,60 EUR Unit: pcs
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
