Standards | IEEE 802.3u/ab/z/x/q |
---|---|
Copper ports | 1 Gigabit SFP WAN/LAN Port, 1 Gigabit WAN Port, 4 Gigabit LAN/WAN Ports, 1 USB3.0 (supports USB LTE dongle and USB Storage) |
Flash | 128 MB NAND |
DRAM | 512 MB DDR4 |
Antenna | 2.4 GHz 2x 3 dBi dual-band detachable antennas, 5 GHz 3x 4.5 dBi dual-band detachable antennas |
Performance | |
GRE | Unencrypted 624,2 Mb/s, Encrypted 301,5 Mb/s |
WireGuard VPN | 393,5 Mb/s |
Concurrent Session | 150,000 |
New Sessions /Second | 5,100 |
NAT (Static IP) | 937,2 Mb/s / 936,1 Mb/s |
NAT(DHCP) | 945,8 Mb/s / 940,6Mb/s |
NAT(PPPoE) | 942,9 Mb/s / 942,9Mb/s |
NAT (L2TP) | 837,4 Mb/s / 881,5 Mb/s |
NAT (PPTP) | 803,0 Mb/s / 910,5 Mb/s |
IPsec VPN Throughput | ESP-SHA1-AES256 646,9 Mb/s, ESP-SHA256-AES256 642,8 Mb/s, ESP-SHA384-AES256 648,9 Mb/s, ESP-SHA512-AES256 658,4 Mb/s |
OpenVPN | 129,3 Mb/s |
L2TP VPN Throughput | Unencrypted 1034,0 Mb/s, Encrypted 570,0 Mb/s |
PPTP VPN Throughput | Unencrypted 1165,0 Mb/s, Encrypted 209,0 Mb/s |
SSL VPN Throughput | 126,7 Mb/s |
66 Byte Packet forwarding rate | 1,453,489 p/s / 1,453,488 p/s |
1,518 Byte Packet forwarding rate | 81,274 p/s / 91,275 p/s |
Basic functions | |
WAN Connection Type | Static/Dynamic IP, PPPoE, PPTP, L2TP |
MAC Clone | Modify WAN/LAN MAC Address |
DHCP | DHCP Server, DHCP Address Reservation, Multi-IP Interfaces, Multi-Net DHCP |
IPv6 | Developing |
VLAN | 802.1Q VLAN |
IPTV | IGMP v2/v3 Proxy |
Advanced functions | |
ACL | IP/Port/Protocol/Domain Name Filtering |
Advanced Routing | Static Routing, Policy Routing |
Bandwidth Control | IP/Port-based Bandwidth Control, Guarantee & Limited Bandwidth |
Load Balance | Intelligent Load Balance, Application Optimized Routing, Link Backup (Timing§, Failover), Online Detection |
NAT | One-to-One NAT, Multi-Net NAT, Virtual Server, Port Triggering, NAT-DMZ, FTP/H.323/SIP/IPSec/PPTP ALG, UPnP |
Security | SPI Firewall, VPN Passthrough, FTP/H.323/PPTP/SIP/IPsec ALG, DoS Defence, Ping of Death, Local Management |
Session Limit | IP-based Session Limit |
VPN | |
IPsec VPN | 100 IPSec VPN Tunnels, LAN-to-LAN, Client-to-LAN, Main, Aggressive Negotiation Mode, DES, 3DES, AES128, AES192, AES256 Encryption Algorithm, IKEv1/v2, MD5, SHA1 Authentication Algorithm, NAT Traversal (NAT-T), Dead Peer Detection (DPD), Perfect Forward Secrecy (PFS) |
PPTP VPN | PPTP VPN Server, 10 PPTP VPN Clients, 50 Tunnels, PPTP with MPPE Encryption |
L2TP VPN | L2TP VPN Server, 10 L2TP VPN Clients, 50 Tunnels, L2TP over IPSec |
OpenVPN | OpenVPN Server, 10 OpenVPN Clients, 50 OpenVPN Tunnels |
Web Authentication | No Authentication, Simple Password, Hotspot(Local User / Voucher* / SMS* / Radius*), External Radius Sever, External Portal Sever, |
Management | |
Omada App | Yes |
Centralized Management | Omada Cloud-Based Controller, Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller |
Cloud Access | Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) |
Maintenance | Web Management Interface, Remote Management, Export & Import Configuration, SNMP v1/v2c/v3, Diagnostics (Ping & Traceroute), NTP Synchronize, Syslog Support |
Management Features | Automatic Device Discovery, Intelligent Network Monitoring, Abnormal Event Warnings, Unified Configuration, Reboot Schedule, Captive Portal Configuration, ZTP (Zero-Touch Provisioning) |
Dimensions | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
Operating temperature | 0°C ÷ 40°C |
Operating humidity | 10% ÷ 90%, non-condensing |
Power | 12VDC / 2A Power Adapter |
Max Power Consumption | EU 16.8W (with USB 3.0 connected), 11.8W (without USB 3.0 connected), US 22.7W (with USB 3.0 connected) 18.2W (without USB 3.0 connected) |
Certificates | CE, FCC, RoHS |
Manufacturer | TP-Link |
Net Price: 120,00 EUR Unit: pcs
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
