SwitchesTP-LINK#09323

Unmanaged switch, 5x 10/100/1000 RJ-45, PoE++IN (TP-Link TL-SF1005P-PD)

  • Ports: 5 10 Mbps/100 Mbps/1 Gbps RJ45 ports
  • 1-Port Gigabit PoE++ In and 4-Port PoE+ Out: Supports up to 66 W / 47 W / 21 W/ 9 W PoE budget output when powered by 802.3bt Type 4, 802.3bt Type 3, 802.3at, and 802.3af PoE standard, respectively.*
  • Long-Range PoE+: With Extend Mode**, PoE transmission distance reaches up to 250 m, perfect for surveillance camera deployment in large areas.
  • PoE Auto Recovery: It guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices.
  • Metal Casing: Durable metal casing and desktop/wall-mounting design are well-suited for different environments.
  • Silent Operation: Industry-leading fanless design ensures silent operation, ideal for any home or business.
  • Plug and Play: No configuration and installation required.
  • Power Supply: The product only supports PoE power supply, not AC or DC power supply.
Standards IEEE 802.3i,
IEEE 802.3u,
IEEE 802.3ab ,
IEEE 802.3af,
IEEE 802.3at,
IEEE 802.3bt,
IEEE 802.3x,
IEEE 802.1p
Copper ports 5x 10/100/1000 Mbps RJ-45
PoE In Ports 5 compliance with 802.3af/at/bt Type3/bt Type4
PoE Out Ports 1-4 compliance with 802.3af/at
PoE Power Budget 66 W when powered by 802.3bt Type 4 (90 W),
47 W when powered by 802.3bt Type 3 (60 W),
21 W when powered by 802.3at (30 W),
9 W when powered by 802.3af (15.4 W)
Backbound Bandwidth 10Gbps
Mac Address Table 2K
Software features
Advanced Features Extend Mode Button (Ports 1–2,
Up to 250 m PoE power supply and data transmission),
PoE Auto Recovery (Ports 1-4),
Mac Address Auto-Learning and Auto-Aging,
IEEE 802.3x Flow Control,
802.1p/DSCP QoS,
IGMP Snooping
Transfer Method Store-And-Forward
Dimensions 6,2 4,0 1,0 in. (158 101 25 mm)
Operating Temperature 0℃~40℃ (32℉~104℉)
Storage Temperature -40℃~70℃ (-40℉~158℉)
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing
Power Only Powered by PoE Device
Power Consumption 2.68 W (90W PoE In,
with no PD connected),
68.59 W (90W PoE In,
with 66 W PD connected)
Max Heat Dissipation 9.112 BTU/h (90W PoE In,
with no PD connected),
233.206 BTU/h (90W PoE In,
with 66 W PD connected)
Certificates CE,
FCC,
RoHS
Manufacturer TP-Link

« previous product  |  next product »     » show on list«» Switches «
TAGS: PoE plus
Net Price: 30,80 EUR  Unit: pcs
Minimal order quantity: 1 x pcs
Quantity in the smallest collective package: 1 x pcs
