MENU#08534
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p |
|---|---|
| Copper ports | 8x 10/100/1000 Mbps RJ-45 |
| Auto MDI/MDI-X | yes |
| Auto-negotiation (Nway) | yes |
| Switching architecture / speed | Store and Forward |
| Packet flow control | Flow-Control, Back-Pressure |
| MAC Address Table | 8K |
| Packet Buffer Memory | 2Mb |
| Packet Forwarding Rate | 11.9Mpps |
| Jumbo Frame | 16KB |
| Quality of Service | Support Port Based/802.1p Based priority, Support 4 priority queues, Rate Limit, Storm Control |
| L2 Features | IGMP Snooping, Link Aggregation, Port Mirroring, Cable Diagnostics, Loop Prevention |
| VLAN | Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs), MTU/Port/Tag VLAN |
| Transmission Method | Store-And-Forward |
| Housing / case type | desktop, metal |
| Dimensions | 158x101x25 mm (6.2x4.0x1.0 cala) |
| Operating temperature | 0°C ÷ 40°C |
| Operating humidity | 10% ÷ 90%, non-condensing |
| Power | 100-240VAC, 50/60Hz |
| Certificates | CE, FCC, RoHS |
| Warranty | 5 years |
| Manufacturer | TP-Link |
Net Price: 20,90 EUR Unit: pcs
|
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
| [+]add item to comparison | show comparison [0] |
