Tapo C645D KIT
Outdoor Dual-Lens Security Wi-Fi Camera, Solar Panel (TP-Link Tapo C645D Kit)
- Dual 2K Lenses for Wide Coverage and Precise Zoom – Features a fixed 2K ultra-wide 165° lens and a 2K pan/tilt telephoto lens for sharp, zoomed-in detail. Independent lens control ensures precise monitoring.
- Panoramic Coverage of Two Areas at Once - A fixed wide-angle lens keeps one area in view, while the pan/tilt lens offers a 360° horizontal view of another.
- Detect People, Vehicles & Pets Without a Subscription - The Tapo C645D KIT accurately identifies people, vehicles, and pets, minimizing false alerts and unnecessary notifications.
- Synchronized Smart Tracking - When enabled on the Tapo App, the pan/tilt lens automatically tracks motion detected by the fixed camera, delivering comprehensive surveillance so you never miss a moment.
- One-Tap Smart Focus - Tap anywhere on the live wide-angle view and the pan/tilt camera will instantly zoom and center the camera on that point. See critical details clearly for more accurate monitoring.
- One Setup is All It Takes – Just 1 hour of sunlight powers the camera for a full day.§ The 10,000 mAh rechargeable backup battery lasts up to 4 months per charge, ensuring reliable operation even during extended cloudy periods.△
- Versatile Night Vision Modes - Choose vivid full-color night vision with spotlights for detailed clarity, or switch to infrared for discreet, power-efficient monitoring—even in complete darkness.
- Dual-Band Wi-Fi Connectivity - The Tapo C645D supports both 5 GHz and 2.4 GHz Wi-Fi bands for speed and range flexibility. The 5 GHz connection offers faster connections at shorter distances while the 2.4 GHz connection provides a longer range.
Built to Last - With an IP65 weatherproof rating, the Tapo C645D KIT resists rain, dust, and snow, ensuring durability in all environments.
HARDWARE FEATURES:
Button: 1× POWER Button, 1× RESET Button, 1× MicroSD Card Slot (Up to 512GB)
Power Source: Built-in Rechargeable Lithium-ion Battery
Solar Panel: Tapo A201
Input Voltage: Adapter Input 100-240 V, 50/60 Hz
Output Voltage: Adapter Output 5.0 V, 1.0 A
Solar Panel Max Charging Voltage: 5.2 V
Solar Panel Max Charging Power: 2.5 W
Dimensions( H X W X D ): Camera Dimensions 5.19 × 3.22 × 6.31 in (132 × 82 × 160 mm), Solar Panel Dimensions 6.82 × 4.74 × 0.61 in (173 × 120 × 15.5 mm)
SOLAR PANEL
Connection Capacity: A solar panel can only connect to one camera.
Output Port: Type-C
WIRELESS FEATURES:
Wireless Data Rates: IEEE 802.11a/b/g/n, 2,4 GHz/5 GHz Wi-Fi
Protocol: TCP/IP, ICMP, DNS, HTTPS, TCP, UDP
Wireless Encryption: AES Encryption with SSL/TLS, WPA/WPA2-PSK/WPA3
CAMERA:
Image Sensor: 1/2.8“
Resolution: Fixed Lens 2K 3MP (2304 × 1296 px), Pan/Tilt Lens: 2K 3MP (2304 × 1296 px)
Lens: Lens_Wide Angle- Focal Length 2.53 mm, Aperture F1.6, Field of View 165.1° (Diagonal), 137.6°(Horizontal), 73°(Vertical), Lens_Telephone- Focal Length 6mm, Aperture F1.6, Field of View 65.5° (Diagonal), 56.5°(Horizontal), 30.6°(Vertical)
Night Vision: 850 nm IR LED up to 40 ft (12m)
Lighting: 6× Built-in Spotlights Motion Activated, App-Controlled, 2× Alarm Lights, 1× Indicator LED
Video Compression: H.264
Frame Rate: 15/20 fps
ACTIVITY NOTIFICATIONS
Input Trigger: Motion detection
Output Notification: Push notification
AUDIO:
Audio Communication: 2-Way
Audio Input: Built-in microphone
Audio Output: Built-in speaker
OTHERS:
Package Contents: Tapo C645D Camera × 1, Mounting Bracket × 1, Camera Mount Adapter × 1, USB Adapter Cable × 1, Tapo A201 Solar Panel × 1, Tapo A201 Solar Panel Bracket × 1, Base Cover × 1, Extension Wire × 1, Cable Zip Tie × 1, Mounting Screws × 7, Mounting Anchors × 7, Mounting Template, Stickers × 2, Quick Start Guide
Environment: Operating Temperature -20°~45° (-4°~113°), Storage Temperature -40°~60° (-40°~140°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing
