| Standards | IEEE 802.11n, IEEE 802.11b/g 2,4 GHz, IEEE 802.11ac/n/a 5 GHz |
|---|---|
| Ports | 1x 10/100/1000 Mbps RJ-45 PoE (LAN) |
| Frequency range | 2,4 GHz and 5 GHz |
| Modulation | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM |
| Operating modes | AP Mode, Multi-SSID Mode, AP Client Mode, Repeater Mode (WDS / Universal), AP+ Bridge mode |
| Max. speed | 1201 Mbps at 5 GHz, 574 Mbps at 2.4 GHz |
| Antenna | 4 Fixed High Performance Antennas |
| WLAN security | WEP 64/128/152-bit, WPA, WPA-PSK, WPA2, WPA2-PSK, TKIP, AES |
| WLAN features | 3T3R MIMO, CCA, QSS button, 4x SSIDs, VLAN support |
| Auto MDI/MDIX | yes |
| Dimensions | 8.9×5.7×1.5 in (225×145.5×37mm) |
| Operating temperatures | 0°C ÷ 40°C |
| Operating humidity | 5% ÷ 90%, non-condensing |
| Power | 48V/0,375A |
| Certificates | CE, FCC, RoHS |
| Manufacturer | TP-Link |
|   | [price  ] |
