#04658
Standard ACTP-LINKEAP225

1350Mbps Outdoor Wireless Access Point, AC1350 (TP-Link EAP225)

  • Simultaneous 450Mbps on 2.4GHz and 867Mbps on 5GHz totals 1317Mbps Wi-Fi speeds
  • Free EAP Controller Software lets administrators easily manage hundreds of EAPs
  • Support Power over Ethernet(802.3af) for convenient and affordable installation
  • Captive portal provides a convenient method for guest authentication
  • Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections
Standards IEEE 802.11ac/n/g/b/a
Ports Gigabit Ethernet (RJ-45) Port *1 (ETH1 Support IEEE802.3af PoE)
Frequency range 2.4GHz and 5GHz
Signal Rate 5GHz Up to 867Mbps,
2.4GHz Up to 450Mbps
EIRP CE <20dBm(2,4GHz) <23dBm(5GHz),
FCC <27dBm
Wireless Functions Multiple SSIDs (Up to 16 SSIDs,
8 for each band),
Enable/Disable Wireless Radio,
Automatic Channel Assignment,
Transmit Power Control (Adjust Transmit Power on dBm),
QoS(WMM),
Airtime Fairness,
Beamforming,
Band Steering,
Load Balance,
Rate Limit,
Link Aggregation,
Reboot Schedule,
Wireless Schedule,
Wireless Statistics based on SSID/AP/Client
Wireless Security Captive Portal Authentication,
Access Control,
Wireless Mac Address Filtering,
Wireless Isolation Between Clients,
SSID to VLAN Mapping,
Rogue AP Detection,
802.1X Support,
64/128/152-bit WEP / WPA / WPA2-Enterprise,
WPA-PSK / WPA2-PSK
EAP Controller Software Yes
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1, v2c
System Logging Local/Remote Syslog Local/Remote Syslog
Telnet Yes
Web-based Management HTTP/HTTPS
L3 Management Yes
Multi-site Management Yes
Management VLAN Yes
Antenna 3 Internal Omni 2.4GHz- 4dBi,
5GHz- 5dBi
Dimensions 8.1 7.1 1.5 in. (205.5 181.5 37.1 mm)
Power PoE or External 12VDC / 1.5A Power Supply
Power Consumption 10.5 W
Mounting Ceiling /Wall Mounting (Kits included)
Physical Security Lock Kensington Lock Slot
Watch Dog Yes
Operating Temperature 0C~60C (-32℉~144℉)
Storage Temperature -40℃~70℃ (-40℉~158℉)
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing
Package Contents AC1200 Wireless Dual Band Gigabit Access Point EAP225,
Power Adapter,
Mounting Kits,
Installation Guide
System Requirements Microsoft Windows XP,
Vista,
Windows 7,
Windows 8,
Windows10
Certificates CE,
FCC,
RoHS
Warranty 5 years

TAGS: PoE
Net Price: 79,20 EUR  Unit: pcs
Minimal order quantity: 1 x pcs
Quantity in the smallest collective package: 1 x pcs
x pcs
