Physical Ports | |
---|---|
10/100/1000 Base-T(X) Ports in RJ45 Auto MDI/MDIX (with PoE) | 8 |
10/100/1000 Base-T(X) Ports in RJ45 Auto MDI/MDIX | 4 |
100/1000 SFP | 2 |
RS-232 Serial Console Port | RS-232 in RJ45 connector with console cable (115200bps 8 N 1) |
Technology | |
Ethernet Standards | IEEE 802.3 for 10Base-T, IEEE 802.3u for 100Base-TX and 100Base-FX, IEEE 802.3ab for 1000Base-T, IEEE 802.z for 1000Base-X, IEEE 802.3x for Flow control, IEEE 802.3ad for LACP (Link Aggregation Control Protocol), IEEE 802.1p for COS (Class of Service), IEEE 802.1Q for VLAN Tagging, IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol), IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol), IEEE 802.1x for Authentication, IEEE 802.1AB for LLDP (Link Layer Discovery Protocol), IEEE 802.3at PoE specification (up to 30 Watts per port for P.S.E.) |
MAC Table | 8192 MAC addresses |
Priority Queues | 8 |
Processing | Store-and-Forward |
Switching latency | 7 µs |
Switching bandwidth | 28 Gbps |
Max. Number of Available VLANs | 256 |
IGMP multicast groups | 128 for each VLAN |
Port rate limiting | User Define |
Security Features | Enable/disable ports, MAC based port security, Port based network access control (802.1x), VLAN (802.1q ) to segregate and secure network traffic, Radius centralized password management, SNMPv3 encrypted authentication and access security |
Software Features | STP/RSTP (IEEE 802.1D/w), Redundant Ring (O-Ring) with recovery time less than 30ms over 250 units, TOS/Diffserv supported, Quality of Service (802.1p) for real-time traffic, VLAN (802.1Q) with VLAN tagging and GVRP supported, IGMP Snooping for multicast filtering, Port configuration, Port status, Port statistics, Port monitoring, Port security, Modbus TCP |
Network Redundancy | O-Ring, Open-Ring, O-Chain, MRP, MSTP (RSTP/STP compatible) |
LED Indicators | |
Power Indicator (PWR) Green | Power LED x 3 |
Ring Master indicator | Green - indicates system operated in O-Ring Master mode |
Ring Indicator | Green - Indicates that the system operating in O-Ring mode, Green Blinking - Indicates that the Ring is broken. |
Fault indicator | Amber - Indicates unexpected event occurred |
100/1000Base-X SFP Port Indicator | Green for port Link/Act. |
10/100/1000TX RJ45 port indicator | Dual color LED - Green for 1000Mbps Link/Act indicator. Amber for 10/100Mbps Link/Act indicator |
PoE indicator | Green - PoE enabled LED x 8 |
Power | |
Input power | Dual DC inputs. 12 ~ 57VDC on 6-pin terminal block |
Power consumption (typical) | 13.2Watts (power device not included) |
PoE Power Output | 12 ~ 24VDC - total power budget is 60Watts with maximum 30Watts per port, 24 ~ 57VDC - total power budget is 120Watts with |
maximum 30Watts per port | |
Overload current protection | present |
Reverse polarity protection | not present |
Physical Characteristic | |
Enclosure | IP-30 |
Dimension (W x D x H) | 74.3 x 109.2 x 153.6 mm |
Weight | 1270g |
Environmental | |
Storage Temperature | -40÷85°C(-40÷185°F) |
Operating Temperature | -40÷70°C (-40÷158°F) |
Operating Humidity | 5%÷95% Non-condensing |
Regulatory approvals | |
EMI | FCC Part 15, CISPR (EN55022) class A |
EMS | EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11 |
Shock | IEC60068-2-27 |
Free Fall | IEC60068-2-32 |
Vibration | IEC60068-2-6 |
Safety | EN60950 |
Warranty | |
Warranty period | 5 years |
