M2M DevicesORING NETWORKINGIMG-W6121+-4G-M12

Industrial Cellular M2M Gateway 4G LTE, 1x 10/100/1000 M12 PoE + 1x 802.11a/b/g/n (WLAN) + 1x RS-232 (ORing IMG-W6121+-4G-M12)

IMG-W6121+-M12 is an innovative 2 port RS-232 and IEEE802.11 a/b/g/n WLAN Access Point VPN gateway with 1 port 10/100/1000Base-T(X) ports. It could be configured to connect to the internet by dialing up 3.5G/4G cellular modem to fulfill demands of various applications rapidly and construct the WLAN environment. IMG-W6121+-M12 has IP-67 grade waterproof casing and PoE power input which enables IMG-W6121+-M12 to be deployed in any outdoor environment to fulfill customer's requirement. In addition, IMG-W6121+-M12 can also transfer SSL encryption data into 5 host PCs simultaneously for backup purposes. Therefore, IMG-W6121+-M12 is one of the best solutions for applications of wireless and serial communication.
Physical Ports
10/100/1000 Base-T(X) Ports M12 Auto MDI/MDIX with PoE P.D. 2 (4-pin M12 D-coding connector)
SIM Card Slot 1
WLAN interface
Antenna Connector 2xN-Type Female
Modulation IEEE802.11a OFDM with BPSK,
QPSK,
QAM,
64QAM
Modulation IEEE802.11b CCK,
DQPSK,
DBPSK
Modulation IEEE802.11g/n OFDM with BPSK,
QPSK,
16QAM,
64QAM
Frequency Band 2.412~2.472 Ghz (13 channels)
Transmission Rate IEEE802.11b 1/2/5.5/11 Mbps,
IEEE802.11g 6/9/12/18/24/36/48/54 Mbps,
IEEE802.11n UP to 150 Mbps
Transmit Power 802.11a 12dBm ± 1.5dBm,
802.11b 19dBm ± 1.5dBm@11Mbps,
802.11g 17dBm ± 1.5dBm@54Mbps,
802.11gn HT20 16.5dBm ± 1.5dBm @MCS7,
802.11n HT40 14.5dBm ± 1.5dBm @MCS7
Receiver Sensitivity 802.11a -68dBm ± 2dBm@54Mbps,
802.11b -90dBm ± 2dBm@1Mbps,
802.11g -72dBm ± 2dBm@54Mbps,
802.11n HT20 -68dBm ± 2dBm@MCS7
Encryption Security WEP (64-bit ,128-bit key),
WPA/WPA2 PSK - TKIP and AES encryption (802.11i),
802.1X/RADIUS Authentication supported
Cellular Interface
Antenna Connector 1 x SMA Female
Cellular Standard GSM/GPRS/EGPRS/EDGE/WCDMA/HSDPA/HSUPA/LTE
Band Option Europe(EU grade) LTE - 2100(B1)/1800(B3)/2600(B7)/900(B8)/800(B20) MHz,
UMTS/HSDPA/HSUPA/HSPA+/DC-HSPA+ - 800/850/900/1900/2100 MHz,
GSM/GPRS/EDGE - 850/900/1800/1900 MHz
Serial Ports
Connector 2 (8-pin M12 A-coding Male connector)
Operation Mode RS-232
Serial Baud Rate 110 bps to 115.2 Kbps
Data Bits 5, 6, 7, 8
Parity odd,
even,
none,
mark,
space
Stop Bits 1, 1.5, 2
RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND
RS-422 Tx+, Tx-, Rx+, Rx-, GND
RS-485 (4-wire) Tx+, Tx-, Rx+, Rx-, GND
RS-485 (2-wire) Data+, Data-
Flow Control XON/XOFF,
RTS/CTS,
DTR/DSR
Network Protocol ICMP,
IP,
TCP,
UDP,
DHCP,
BOOTP,
DNS,
SNMP V1/V2c,
HTTPS
LED Indicators
Power Indicator Green On - Power is on
10/100/1000TX M12 port indicator Green for port Link/Act
Serial TX / RX LEDs Red - Serial port is receiving data,
Green - Serial port is transmitting data
WLAN LED Green On
Power
Redundant Input Power 48VDC on PoE port compliant with IEEE802.3af standard
Power consumption (typical) 6.5W
Physical Characteristic
Enclosure IP-67
Dimension (W x D x H) 310 (W) x 310(D) x 87 (H) (12.2 x 12.2 x 3.4 inch)
Weight 2653g
Environmental
Storage Temperature -4085C (-40185F)
Operating Temperature -2570C (-13158F)
Operating Humidity 5%95% Non-condensing
Regulatory approvals
EMI FCC Part 15,
CISPR (EN55022) class A
EMS EN61000-4-2 (ESD),
EN61000-4-3 (RS),
EN61000-4-4 (EFT),
EN61000-4-5 (Surge),
EN61000-4-6 (CS),EN61000-4-8,
EN61000-4-11
Shock IEC60068-2-27
Free Fall IEC60068-2-31
Vibration IEC60068-2-6
Safety EN60950-1
Warranty
Warranty period 3 years

« previous product  |  next product »     »show on list«
* For special orders only
Net Price: 1 580,00 EUR  Unit: pcs
Minimal order quantity: 1 x pcs
Quantity in the smallest collective package: 1 x pcs
x pcs
