#06614
NEW
Industrial SwitchesORING NETWORKINGIGS-C1080

Unmanaged switch, 8x 10/100/1000 RJ-45 (ORing IGS-C1080)

Physical Ports
10/100/1000 Base-T(X) Ports in RJ45 Auto MDI/MDIX 8
Technology
Ethernet Standards IEEE 802.3 for 10BaseT,
IEEE 802.3u for 100BaseT(X),IEEE 802.3ab for 1000Base-T,
IEEE 802.3x for Flow control
MAC Table 4k MAC addresses
Processing Store-and-Forward
Power
Input power 1248VDC on 2-pin terminal block
Overload current protection present
Reverse polarity protection present
Physical Characteristic
Enclosure IP-40
Dimension (W x D x H) 43,5mm x 64mm x 103mm
Environmental
Storage Temperature -4085C (-40185F)
Operating Temperature -4075C (-40167F)
Operating Humidity 5%95% Non-condensing
Regulatory approvals
EMC CE EMC (EN 55032,
EN 55035),
FCC Part 15 B
EMI CISPR32,
EN 61000-3-2,
EN 61000-3-3,
FCC Part 15 B class A
EMS EN61000-4-2 (ESD),
EN61000-4-3 (RS),
EN61000-4-4 (EFT),
EN61000- 4-5 (Surge),
EN61000-4-6 (CS),
EN61000-4-8(PFMF)
Safety EN62368-1
Warranty
Warranty period 5 years

* For special orders only
Net Price: 136,00 EUR  Unit: pcs
Minimal order quantity: 1 x pcs
Quantity in the smallest collective package: 1 x pcs
x pcs
[+]add item to comparison | show comparison [0]
