Cables coaxial type › MRC 400 ECO
MRC 400 ECO coaxial cable, Draka, 50 Ohm (PE), 100 m
High performance, professional outdoor coaxial cable for WLAN communication (2,4 GHz, WiMAX, 5 GHz) with a CCA inner conductor (Copper Clad Aluminium). Draka Comteq.
| Internal wire | 2.74 mm/CCA |
|---|---|
| Insulation | Ø7.24 mm |
| Shield | AL-PET Foil, bonded to the dielectric + Aluminium braid |
| External coating | 10.3 mm/PE/black |
| Attenuation table | |
| 30 MHz | 2.2 dB/100m |
| 150 MHz | 5 dB/100m |
| 220 MHz | 6.1 dB/100m |
| 450 MHz | 8.9 dB/100m |
| 900 MHz | 12.8 dB/100m |
| 1800 MHz | 18.6 dB/100m |
| 2500 MHz | 22.3 dB/100m |
| 5200 MHz | 33.6 dB/100m |
| 5800 MHz | 35.5 dB/100m |
Marked each meter, in rolls. Can use connector for H1000.
Connectors for MRC 400 ECO (H1000)
#02018 N male connector, crimp type, H1000
#02019 N female connector, crimp type, H1000
Crimping tools MRC 400 ECO (H1000)
#02330 Coaxial ratchet crimping tool (CT-336K)
#04293 Coaxial ratchet crimping tool (HT-336K)
Connectors for MRC 400 ECO (H1000)
#02018 N male connector, crimp type, H1000
#02019 N female connector, crimp type, H1000
Crimping tools MRC 400 ECO (H1000)
#02330 Coaxial ratchet crimping tool (CT-336K)
#04293 Coaxial ratchet crimping tool (HT-336K)
Net Price: 122,00 EUR Unit: roll 100m
|
|
Minimal order quantity: 1 x roll 100m Quantity in the smallest collective package: 1 x roll 100m |
