TP-LINK is a largest Chinese network hardware manufacturer for SOHO market. Company was founded in 1996. Their market share in networking products is still growing. TP-LINK cooperates with over 600 distributors in China and rest of the world. There are over 100 experienced engineers working for TP-LINK in two factories with 21 production lines. Perfect technical support and management system compliant with ISO9001:2000 gives warranty of reliability and stability of their devices. Quality of products was confirmed with a lot of awards in many independent device tests. TP-LINK is also manufacturing OEM versions of hardware for other network device manufacturers. TP-LINK offers includes:
Manufacturer's website: http://www.tp-link.com |
Standards | IEEE 802.11ax/ac/n/g/b/a |
---|---|
Ports |
10/100/1000Mbps (RJ-45) Port *1, Downlink- 10/100/1000Mbps Ethernet Port*3 (One port supports PoE OUT. The PoE OUT feature requires 802.3at PoE+ input and the maximum output is 13W.) |
Frequency range | 2.4GHz and 5GHz |
Signal Rate |
5GHz Up to 1201Mbps, 2.4GHz Up to 574Mbps |
EIRP |
CE <20dBm(2,4GHz) <23dBm(5GHz), FCC <27dBm |
Wireless Functions |
Multiple SSIDs (Up to 16 SSIDs, 8 for each band), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Airtime Fairness, Beamforming, Band Steering, Load Balance, Rate Limit, Link Aggregation, Reboot Schedule, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
Wireless Security |
Captive Portal Authentication, Access Control, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
Omada App | Yes |
Centralized Management |
Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller |
Cloud Access |
Yes (Through OC300, OC200, or Omada Software Controller) |
EAP Controller Software | Yes |
Email Alerts | Yes |
LED ON/OFF Control | Yes |
Management MAC Access Control | Yes |
SNMP | v1, v2c |
System Logging Local/Remote Syslog | Local/Remote Syslog |
Telnet | Yes |
Web-based Management | HTTP/HTTPS |
L3 Management | Yes |
Multi-site Management | Yes |
Management VLAN | Yes |
Antenna |
2 Dual-Band Antennas, 2.4GHz- 2*3dBi, 5GHz- 2*4dBi |
Dimensions | 143 × 86 × 42,6mm (5.6 × 3.4 × 1,7 in) |
Power | 802.3af/802.3at PoE |
Power Consumption |
EU 10W (802.3at PoE, PoE Out off), US 11.5W (802.3at PoE, PoE Out off) |
Mounting | Wall Plate Mounting |
Physical Security Lock | Kensington Lock Slot |
Watch Dog | Yes |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
EAP655-Wall, Mounting Kits, Installation Guide |
System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 11, Linux |
Certificates |
CE, FCC, RoHS |
Warranty | 5 years |
HARDWARE FEATURES: | |
---|---|
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
3 10/100/1000Mbps LAN Ports, 1 2.5G WAN Port |
Button | WPS/Reset Button |
Dimensions (W X D X H) | 8.2 × 6.8 × 1.6 in (208.8 × 171.6 × 41.7 mm) |
Antenna | 4× 5 dBi Fixed Omni-Directional Antennas |
WIRELESS FEATURES: | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 2402 Mbps (802.11ax), 2.4 GHz@ 574 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, WMM |
Wireless Security | WPA-PSK / WPA2-PSK/ WPA3 |
SOFTWARE FEATURES: | |
WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Management |
Access Control, Local Management, Remote Management |
DHCP |
Server, DHCP Client List |
NAT Forwarding |
Port Forwarding, Port Triggering, UPnP, DMZ |
Firewall Security |
SPI Firewall, IP and MAC Address Binding |
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
VPN Passthrough |
OpenVPN, PPTP supported |
OTHERS: | |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
HARDWARE FEATURES: | |
---|---|
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
3 10/100/1000Mbps LAN Ports, 1 1G/100Mbps WAN Port, 1 2.5G WAN Port, 1 USB-A 3.0 Port |
Button |
WPS/Reset Button, Wireless On/Off Button, Power On/off Button |
Power Supply | 12V/1.5A |
Dimensions (W X D X H) | 261.1 × 134.5 × 41.0 mm |
Antenna | 4 × External Antennas |
WIRELESS FEATURES: | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 2402 Mbps (802.11ax), 2.4 GHz@ 574 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, Guest Network, DFS, MU-MIMO, OFDMA |
Wireless Security |
WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x) encryption |
SOFTWARE FEATURES: | |
WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP (Dual Access)/L2TP (Dual Access)/BigPond |
DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP relay |
Quality of Service | Advanced Gaming Qos powered by TrendMicro |
Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
Dynamic DNS |
DynDns, Comexe, NO-IP |
VPN Pass-Through |
PPTP, L2TP, IPSec Passthrough |
Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
Management |
Access Control, Local Management, Remote Management |
Guest Network | 2.4GHz guest network × 1, 5GHz guest network × 1 |
OTHERS: | |
Certification |
CE, FCC, IC, RoHS |
System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Manufacturer | TP-Link |
Standards | IEEE 802.11ax/ac/n/g/b/a |
---|---|
Ports | 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE and Passive PoE) |
Button | Reset |
Frequency range | 2.4GHz and 5GHz |
Signal Rate | 574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz) |
EIRP |
CE < 20 dBm (2.4GHz, EIRP); < 23dBm (5 GHz, band1 & band 2, EIRP);< 30 dBm (5 GHz, band 3, EIRP); FCC < 30 dBm (2.4 GHz); < 30 dBm (5 GHz) |
Wireless Functions |
Multiple SSIDs (Up to 16 SSIDs, 8 for each band), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Airtime Fairness, Beamforming, Band Steering, Load Balance, Rate Limit, Link Aggregation, Reboot Schedule, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
Wireless Security |
Captive Portal Authentication, Access Control, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
MANAGEMENT | |
Omada App | Yes |
Centralized Management |
Omada Cloud-Based Controller, Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller |
Cloud Access |
Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
Email Alerts | Yes |
LED ON/OFF Control | Yes |
Management MAC Access Control | Yes |
SNMP |
v1, v2c, v3 |
System Logging Local/Remote Syslog | Local/Remote Syslog |
SSH | Yes |
Web-based Management | HTTP/HTTPS |
L3 Management | Yes |
Multi-site Management | Yes |
Management VLAN | Yes |
Antenna |
2.4 GHz 2× 8 dBi, 5 GHz 2× 10 dBi, Beamwidth 120° Horizontal; 30° Vertical |
Coverage |
2.4 GHz 200+ m, 5 GHz 500+ m |
Dimensions | 9.1 × 8.2 × 2.8 in (230 × 207.5 × 69.7 mm) |
Power |
802.3at PoE, 48V/0.5A Passive PoE (PoE Adapter Included) |
Power Consumption |
EU 12.5W (802.3at PoE or Passive PoE), US 14.7W (802.3at PoE or Passive PoE) |
Weatherproof Enclosure | IP68 |
Mounting | Pole/Wall Mounting (Kits included) |
Physical Security Lock | Yes |
Operating Temperature | -30°C~70°C (-22℉~158℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
Access Point EAP650 D120-Outdoor, Mounting Kits, Waterproof Kits, Installation Guide |
System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 10, Linux |
Certificates |
CE, FCC, RoHS |
Standards | IEEE 802.11ax/ac/n/g/b/a |
---|---|
Ports | 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE and Passive PoE) |
Button | Reset |
Frequency range | 2.4GHz and 5GHz |
Signal Rate | 574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz) |
EIRP |
< 20 dBm (2.4GHz, EIRP); < 23dBm (5 GHz, band1 & band 2, EIRP);< 30 dBm (5 GHz, band 3, EIRP) |
Wireless Functions |
Multiple SSIDs (Up to 16 SSIDs, 8 for each band), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Airtime Fairness, Beamforming, Band Steering, Load Balance, Rate Limit, Link Aggregation, Reboot Schedule, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
Wireless Security |
Captive Portal Authentication, Access Control, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
MANAGEMENT | |
Omada App | Yes |
Centralized Management |
Omada Cloud-Based Controller, Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller |
Cloud Access |
Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
Email Alerts | Yes |
LED ON/OFF Control | Yes |
Management MAC Access Control | Yes |
SNMP |
v1, v2c, v3 |
System Logging Local/Remote Syslog | Local/Remote Syslog |
SSH | Yes |
Web-based Management | HTTP/HTTPS |
L3 Management | Yes |
Multi-site Management | Yes |
Management VLAN | Yes |
Antenna |
Built-in Directional Antennas 2.4 GHz 2× 12 dBi, 5 GHz 2× 15 dBi, Beamwidth 30° Horizontal; 30° Vertical |
Dimensions | 8.2 × 2.3 × 9.1 in (207.5 × 58 × 230 mm) |
Power |
802.3at PoE, 48V/0.5A Passive PoE (PoE Adapter Included) |
Power Consumption |
EU 12.5W (802.3at PoE or Passive PoE), US 14.7W (802.3at PoE or Passive PoE) |
Weatherproof Enclosure | IP68 |
Mounting | Pole/Wall Mounting (Kits included) |
Physical Security Lock | Yes |
Operating Temperature | -30°C~70°C (-22℉~158℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
Access Point EAP650 D30-Outdoor, Mounting Kits, Waterproof Kits, Installation Guide |
System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 10, Linux |
Certificates |
CE, FCC, RoHS |
Standards | IEEE 802.11ax/ac/n/g/b/a |
---|---|
Ports | 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE and Passive PoE) |
Button | Reset |
Frequency range | 2.4GHz and 5GHz |
Signal Rate |
802.11ax 8 Mbps to 2402 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80/160), 802.11ac 6.5 Mbps to 1083.3 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80), 802.11n 6.5 Mbps to 300 Mbps (MCS0-MCS15, HT20/40), 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps, 802.11b 1, 2, 5.5, 11 Mbps, 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
EIRP |
CE <20dBm(2,4GHz) <23dBm(5GHz), FCC <27dBm |
Wireless Functions |
Multiple SSIDs (Up to 16 SSIDs, 8 for each band), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Airtime Fairness, Beamforming, Band Steering, Load Balance, Rate Limit, Link Aggregation, Reboot Schedule, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
Wireless Security |
Captive Portal Authentication, Access Control, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
MANAGEMENT | |
Omada App | Yes |
Centralized Management |
Omada Cloud-Based Controller, Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller |
Cloud Access |
Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
Email Alerts | Yes |
LED ON/OFF Control | Yes |
Management MAC Access Control | Yes |
SNMP | v1, v2c |
System Logging Local/Remote Syslog | Local/Remote Syslog |
SSH | Yes |
Web-based Management | HTTP/HTTPS |
L3 Management | Yes |
Multi-site Management | Yes |
Management VLAN | Yes |
Antenna |
2 Dual-Band Antennas, 2.4GHz- 2*4dBi, 5GHz- 2*5dBi |
Dimensions | 280.4×106.5×56.8 mm (without antenna & mounting kit) |
Power |
802.3at PoE, 48V/0.5A Passive PoE (PoE Adapter Included) |
Power Consumption |
EU 12.5W (802.3at PoE or Passive PoE), US 14.7W (802.3at PoE or Passive PoE) |
Weatherproof Enclosure | IP67 |
Mounting | Pole/Wall Mounting (Kits included) |
Physical Security Lock | Yes |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
Access Point EAP650-Outdoor, Passive PoE Adapter, Power Cord, Mounting Kits, Waterproof Kits, Waterproof Antenna, Installation Guide |
System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 10, Linux |
Certificates |
CE, FCC, RoHS |
HARDWARE FEATURES: | |
---|---|
Interface | PCI Express x1 |
Antenna Type |
Two High-Gain Dual Band Antennas, Magnetized Antenna Base |
Chipset | Intel Wi-Fi 6 Chipset |
WIRELESS FEATURES: | |
Wireless Standards |
5 GHz@ IEEE 802.11ax/ac/n/a, 2,4 GHz@ IEEE 802.11ax/n/g/b, Bluetooth 5.0/4.2/4.0 |
Frequency |
2.4-2.4835GHz, 5.180-5.240GHz, 5.745-5.825GHz |
Signal Rate |
2402Mbps at 5GHz, 574Mbps at 2.4GHz |
EIRP |
5 GHz @ 27 dBm (FCC) / 23 dBm (CE) (EIRP), 2,4 GHz @ 26 dBm (FCC) / 20 dBm (CE) (EIRP) |
Wireless Modes | Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
OTHERS: | |
Dimensions | 3.7 x 4.8 x 0.8 in (95.2 x 120.8 x 21.5 mm) |
Certification |
CE, FCC, RoHS, Wi-Fi |
Package Contents |
Archer TX3000E, Magnetized Antenna Base with 1m RF Cable, Two 5 dBi High Gain Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD |
System Requirements |
Windows 7/8/8.1/10(32/64bits), Windows XP(32/64bits) |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
HARDWARE FEATURES: | |
---|---|
Interface | PCI Express x1 |
Antenna Type | Two High-Gain Dual Band Antennas |
Chipset | Intel Wi-Fi 6 Chipset |
WIRELESS FEATURES: | |
Wireless Standards |
5 GHz@ IEEE 802.11ax/ac/n/a, 2,4 GHz@ IEEE 802.11ax/n/g/b, Bluetooth 5.0/4.2/4.0 |
Frequency |
2.4-2.4835GHz, 5.180-5.240GHz, 5.745-5.825GHz |
Signal Rate |
2402Mbps at 5GHz, 574Mbps at 2.4GHz |
EIRP |
5 GHz @ 27 dBm (FCC) / 23 dBm (CE) (EIRP), 2,4 GHz @ 26 dBm (FCC) / 20 dBm (CE) (EIRP) |
Wireless Modes | Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
OTHERS: | |
Dimensions | 3.7 x 4.8 x 0.8 in (95.2 x 120.8 x 21.5 mm) |
Certification |
CE, FCC, RoHS, Wi-Fi |
Package Contents |
Archer TX50E, Two 5 dBi High Gain Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD |
System Requirements | Windows 10(64-bit) only |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
HARDWARE FEATURES: | |
---|---|
Interface | PCI Express x1 |
Antenna Type | Two High-Gain Dual Band Antennas |
Chipset | Intel Wi-Fi 6 Chipset |
WIRELESS FEATURES: | |
Wireless Standards |
5 GHz@ IEEE 802.11ax/ac/n/a, 2,4 GHz@ IEEE 802.11ax/n/g/b, Bluetooth 5.0/4.2/4.0 |
Frequency |
2.4-2.4835GHz, 5.180-5.240GHz, 5.745-5.825GHz |
Signal Rate |
2402Mbps at 5GHz, 574Mbps at 2.4GHz |
EIRP |
5 GHz @ 27 dBm (FCC) / 23 dBm (CE) (EIRP), 2,4 GHz @ 26 dBm (FCC) / 20 dBm (CE) (EIRP) |
Wireless Modes | Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
OTHERS: | |
Dimensions | 2,4 x 1,4 x 0,45 in (55 x 36 x 11,5 mm) |
Certification |
CE, FCC, RoHS, Wi-Fi |
Package Contents |
Archer TX55E, Two High Gain Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD |
System Requirements | Windows 10(64-bit) only |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
HARDWARE FEATURES: | |
---|---|
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
1× SC/APC GPON Port, 1× 10/100/1000 Mbps WAN/LAN Port, 3× 10/100/1000 Mbps LAN Ports, 1× FXS Port, 1× USB 2.0 Port |
Button |
WPS/Reset Button, Wireless On/Off Button, Power On/off Button, LED On/Off |
Power Supply | 12V/1.5A |
Antenna | 2× External Dual-Band Antennas + 1× Internal 5G Antenna |
Data Rates |
Downstream Speeds 2.488 Gbps (GPON), Upstream Speeds 1.244 Gbps (GPON) |
WIRELESS FEATURES | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 2402 Mbps (802.11ax), 2.4 GHz@ 574 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, Guest Network, DFS, MU-MIMO, OFDMA |
Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption |
SOFTWARE FEATURES | |
WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP (Dual Access)/L2TP (Dual Access)/BigPond |
DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP relay |
Quality of Service | Advanced Gaming Qos powered by TrendMicro |
Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
Dynamic DNS |
DynDns, Comexe, NO-IP |
VPN Pass-Through |
PPTP, L2TP, IPSec Passthrough |
Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
Management |
Local management - WebGUI, Aginet app (for end users), Remote management Aginet ACS, OMCI, TR-069/TR-369, TR-098, TR-181, TR-111, TR-143 for service providers, Aginet APP for end user (need to log in wtih TP-Link ID and bind your device to it), Cloud management - TP-Link Aginet Unified Cloud (TAUC), Guest Network 2.4GHz guest network × 1, 5GHz guest network × 1 |
OTHERS | |
Certification |
CE, FCC, IC, RoHS |
System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Manufacturer | TP-Link |
Page 43 of 66
|
