New Items in Atel Electronics

NEW ITEMS


  • Computer Network Accessories
    • Switches
      • » FAST ETHERNET / UNMANAGED SWITCHES
          #09616

          Unmanaged switch, 8x 10/100 RJ-45, 2x gigabitowe porty, PoE+, desktop (TP-Link Mercusys MS110CMP)

          • 10 Ports: 8× 10/100 Mbps PoE+ Ports + 2× Gigabit non-PoE Ports
          • Two Cables in One: With 8 PoE+ ports, transfers data and power on one single cable
          • High Power PoE+: Support PoE Power up to 30 W for each PoE port and 115 W for all PoE ports*
          • 2× Uplink Ports: MS110CMP provides 2× uplink ports when turning on the isolation mode. One for connecting to the Internet and one for connecting to the NVR.
          • Long-Range up to 250 m: Increases PoE transmission distance to 250 m by Extend Mode**
          • Isolation Mode: One click to divide traffic for specific ports for stability and security
          • Compliant with Powered Devices: Works with IEEE 802.3af/at compliant PDs
          • Plug and Play: Simple to use and saves time and effort
          • PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
          • Durable Metal Casing: Allows for efficient heat dissipation and long network life
          Standards IEEE 802.3/x
          Copper ports 8x 10/100 Mbps RJ-45 (PoE),
          2× 1000 Mbps RJ45 Ports
          PoE Ports RJ45,
          Standard Compliant with 802.3 af/at Powered Devices,
          PoE Ports Port 1- Port 8
          PoE Power Budget 115 W
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Mac Address Table 2K
          Jumbo Frame 2 KB
          Dimensions 171 × 98 × 27 mm (6,7 × 3,9 × 1,1 in)
          Operating temperature 0°C ÷ 40°C
          Storage Temperature -40°C ÷ 70°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          External Power Supply External Power Adapter (Output 53,5V DC / 1,31A)
          Max Power Consumption 3.79W（220 V / 50 Hz,
          no PD connected）,
          130.49W（220 V / 50 Hz,
          with 115W PD connected
          TP-LINK
          Unmanaged switch, 8x 10/100 RJ-45, 2x gigabitowe porty, PoE+, desktop (TP-Link Mercusys MS110CMP)
          Net Price: 29,10 EUR
          product card»
          #09617

          Unmanaged switch, 8x 10/100 RJ-45, 2x gigabitowe porty, PoE+, desktop (TP-Link Mercusys MS110CP)

          • 10 Ports: 8× 10/100 Mbps PoE+ Ports + 2× Gigabit non-PoE Ports
          • Two Cables in One: With 8 PoE+ ports, transfers data and power on one single cable
          • High Power PoE+: Support PoE Power up to 30 W for each PoE port and 65 W for all PoE ports
          • 2× Uplink Ports: MS110CP provides 2× uplink ports when turning on the isolation mode. One for connecting to the Internet and one for connecting to the NVR.
          • Long-Range up to 250 m: Increases PoE transmission distance to 250 m by Extend Mode**
          • Isolation Mode: One click to divide traffic for specific ports for stability and security
          • Compliant with Powered Devices: Works with IEEE 802.3af/at compliant PDs
          • Plug and Play: Simple to use and saves time and effort
          • PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
          • Durable Metal Casing: Allows for efficient heat dissipation and long network life
          Standards IEEE 802.3/x
          Copper ports 8x 10/100 Mbps RJ-45 (PoE),
          2× 1000 Mbps RJ45 Ports
          PoE Ports RJ45,
          Standard Compliant with 802.3 af/at Powered Devices,
          PoE Ports Port 1- Port 8
          PoE Power Budget 65 W
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Mac Address Table 2K
          Jumbo Frame 2 KB
          Dimensions 171 × 98 × 27 mm (6,7 × 3,9 × 1,1 in)
          Operating temperature 0°C ÷ 40°C
          Storage Temperature -40°C ÷ 70°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          External Power Supply External Power Adapter (Output 53,5V DC / 1,31A)
          Max Power Consumption 3.5W（220 V / 50 Hz,
          no PD connected),
          74.93W（220 V / 50 Hz,
          with 65W PD connected
          TP-LINK
          Unmanaged switch, 8x 10/100 RJ-45, 2x gigabitowe porty, PoE+, desktop (TP-Link Mercusys MS110CP)
          Net Price: 23,20 EUR
          product card»
          #09614

          Unmanaged switch, 16x 10/100 RJ-45, 2x Combo Gigabit, PoE, 19" Rack-mounting Bracket (TP-Link Mercusys MS118CP)

          • 16× PoE+ 10/100 Mbps RJ45 ports, 2× Gigabit RJ45 ports, and 2× combo Gigabit SFP slots.
          • High PoE power budget with up to 30 W for each PoE port and 190 W for all PoE ports.
          • Up to 250 m data and power transmission under extend mode specially designed for surveillance system.
          • Priority mode for ports 1–8 to guarantees the quality of sensitive applications like video monitor.
          • Isolation Mode allows one-click client traffic separation for higher security and performance.
          • PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices.
          • Easy to use, with no configuration and installation needed.
          Standards IEEE 802.3i/u/ab/x/p/af/at
          Copper ports 16x 10/100 Mbps RJ-45, 2× Combo Gigabit SFP Slots
          PoE Ports Ports 1–16,
          PoE Power Budget 190 W
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Switching Capacity 7,2 Gbps
          Mac Address Table 8K
          Jumbo Frame 10 KB
          Dimensions 440 × 180 × 44 mm (17,3 × 7,1 × 1,7 in)
          Power 100-240VAC,
          50/60Hz
          Fan Quantity 2 Fans
          TP-LINK
          Unmanaged switch, 16x 10/100 RJ-45, 2x Combo Gigabit, PoE, 19" Rack-mounting Bracket (TP-Link Mercusys MS118CP)
          Net Price: 73,80 EUR
          product card»
      • » GIGABIT ETHERNET / UNMANAGED SWITCHES
          #09596

          Unmanaged switch, 16x 10/100/1000 RJ-45, 11.6", 19" Rack-mounting Bracket (TP-Link LS1016G)

          • 16× 10/100/1000Mbps ports
          • Supports MAC address self-learning, Auto MDI/MDIX and Auto Negotiation
          • Plug & play design
          • QoS ensures smooth traffic for latency sensitive applications such as voice or video
          • Innovative energy-efficient technology saves power consumption
          • Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses
          • Durable metal casing provides improved heat dissipation and ensures a longer product life
          • Desktop or rackmount installation
          Standards IEEE 802.3,
          IEEE 802.3i,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3x,
          IEEE 802.3p
          Copper ports 16x 10/100/1000 Mbps RJ-45
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Packet flow control Flow-Control,
          Back-Pressure
          Forwarding rate 32 Gbps
          Packet Forwarding Rate 23.808Mpps
          MAC Address Table 8K
          Jumbo Frame 15KB
          Green Technology Yes
          Housing / case type 11.6",
          metal
          Dimensions 294x140x44 mm (handles for 19" rack included)
          Operating temperature 0°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100-240V~50/60Hz,
          0,3A
          Max. Power Consumption 7.2 W (110V/60Hz)
          Max Heat Dissipation 24.42 BTU/h (110V/60Hz)
          Certificates FCC,
          CE,
          RoHs
          Warranty period 5 years
          Manufacturer TP-Link
          TP-LINK
          Unmanaged switch, 16x 10/100/1000 RJ-45, 11.6", 19" Rack-mounting Bracket (TP-Link LS1016G)
          Net Price: 44,50 EUR
          product card»
          #09595

          Unmanaged switch, 24x 10/100/1000 RJ-45, 11.6", 19" Rack-mounting Bracket (TP-Link LS1024G)

          • 24× 10/100/1000Mbps ports
          • Supports MAC address self-learning, Auto MDI/MDIX and Auto Negotiation
          • Plug & play design
          • QoS ensures smooth traffic for latency sensitive applications such as voice or video
          • Innovative energy-efficient technology saves power consumption
          • Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses
          • Durable metal casing provides improved heat dissipation and ensures a longer product life
          • Desktop or rackmount installation
          Standards IEEE 802.3,
          IEEE 802.3i,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3x,
          IEEE 802.3p
          Copper ports 24x 10/100/1000 Mbps RJ-45
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Packet flow control Flow-Control,
          Back-Pressure
          Forwarding rate 48 Gbps
          Packet Forwarding Rate 35.712Mpps
          MAC Address Table 8K
          Jumbo Frame 10KB
          Green Technology Yes
          Housing / case type 11.6",
          metal
          Dimensions 294x140x44 mm (handles for 19" rack included)
          Operating temperature 0°C ÷ 45°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100-240V~50/60Hz,
          0,6A
          Max. Power Consumption 12.6 W (110V/60Hz)
          Max Heat Dissipation 42.77 BTU/h (110V/60Hz)
          Certificates FCC,
          CE,
          RoHs
          Warranty period 5 years
          Manufacturer TP-Link
          TP-LINK
          Unmanaged switch, 24x 10/100/1000 RJ-45, 11.6", 19" Rack-mounting Bracket (TP-Link LS1024G)
          Net Price: 61,90 EUR
          product card»
          #09618

          Unmanaged switch, 24x 10/100/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link Mercusys MS124GS)

          • Full Gigabit Ports: 24× 10/100/1000 Mbps Auto-Negotiation RJ45 port supporting Auto-MDI/MDIX
          • Multiple Installation Operation: Steel housing, desktop or wall-mounting design
          • Durable Metal Casing: Allows for efficient heat dissipation and long network life
          • Plug and Play: Simple to use and saves time and effort
          • Power Saving: Green Ethernet technology saves power
          Standards IEEE 802.3/u/x
          Copper ports 8x 10/100/1000 Mbps RJ-45
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Switching Capacity 48 Gbps
          MAC Address Table 8K
          Dimensions 294*140*44mm (11.6*5.5*1.7 in)
          Power 100-240VAC,
          50/60Hz
          TP-LINK
          Unmanaged switch, 24x 10/100/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link Mercusys MS124GS)
          Net Price: 49,00 EUR
          product card»
      • » GIGABIT ETHERNET / INTELLIGENT (SMART SWITCHES)
          #09594

          Smart switch, 8x 10/100/1000 RJ-45, desktop (TP-Link ES208G)

          • 8× 10/100/1000Mbps RJ45 ports
          • Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
          • Centralized Cloud Management via the web or the Omada app†
          • Automatic Loop Prevention, VLAN, and IGMP Snooping
          • Fanless design for silent operation
          • Durable metal casing and desktop/wall mounting design
          Standards IEEE 802.3i,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3af,
          IEEE 802.3x,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 8x 10/100/1000 Mbps RJ-45
          Switching Capacity 16Gbps
          Packet Forwarding Rate 11,9 Mpps
          Mac Address Table 8K
          Jumbo Frame 15 KB
          Packet Buffer Memory 4 Mb
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Quality of Service Support Port-Based/802.1p/DSCP priority,
          Support 4 priority queues,
          Rate Limit,
          Storm Control
          L2 Features IGMP Snooping V1/V2/V3,
          Static Link Aggregation,
          Port Mirroring,
          Cable Diagnostics,
          Loop Prevention,
          PoE Auto Recovery,
          Extend Mode
          VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs),
          MTU/Port/Tag VLAN
          Management
          Omada App Yes. Requires the use of Omada Hardware Controller,
          Omada Cloud-Based Controller,
          or Omada Software Controller.
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller,
          Omada Software Controller
          Cloud Access Yes. Requires the use of Omada Hardware Controller,
          Omada Cloud-Based Controller,
          or Omada Software Controller.
          Zero-Touch Provisioning Yes. Requires the use of Omada Cloud-Based Controller
          Management Features Web-based GUI,
          DHCP Client,
          Cable Diagnostics,
          Automatic Device Discovery,
          Batch Configuration,
          Batch Firmware Upgrading,
          Unified Configuration
          Housing / case type desktop,
          metal
          Dimensions 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)
          Operating temperature -5°C ÷ 45°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power External DC Power Adapter (Output 5 VDC/ 0.6 A)
          Certificates CE,
          FCC,
          RoHS
          Package Contents ES208G,
          Power Cord,
          Installation Guide,
          Resource CD,
          Rubber Feet
          System Requirements Microsoft® Windows® for running Utility
          Warranty 5 years
          Manufacturer TP-Link
          TP-LINK
          Smart switch, 8x 10/100/1000 RJ-45, desktop (TP-Link ES208G)
          Net Price: 26,10 EUR
          product card»
          #09593

          Smart switch, 16x 10/100/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link ES216G)

          • 16× 10/100/1000Mbps RJ45 ports
          • Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
          • Centralized Cloud Management via the web or the Omada app†
          • Automatic Loop Prevention, VLAN, and IGMP Snooping
          • Fanless design for silent operation
          • Durable metal casing and desktop/rack mounting design
          Standards IEEE 802.3i,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3af,
          IEEE 802.3x,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 16x 10/100/1000 Mbps RJ-45
          Switching Capacity 32Gbps
          Packet Forwarding Rate 23,8 Mpps
          Mac Address Table 8K
          Jumbo Frame 15 KB
          Packet Buffer Memory 4 Mb
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Quality of Service Support Port-Based/802.1p/DSCP priority,
          Support 4 priority queues,
          Rate Limit,
          Storm Control
          L2 Features IGMP Snooping V1/V2/V3,
          Static Link Aggregation,
          Port Mirroring,
          Cable Diagnostics,
          Loop Prevention,
          PoE Auto Recovery,
          Extend Mode
          VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs),
          MTU/Port/Tag VLAN
          Management
          Omada App Yes. Requires the use of Omada Hardware Controller,
          Omada Cloud-Based Controller,
          or Omada Software Controller.
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller,
          Omada Software Controller
          Cloud Access Yes. Requires the use of Omada Hardware Controller,
          Omada Cloud-Based Controller,
          or Omada Software Controller.
          Zero-Touch Provisioning Yes. Requires the use of Omada Cloud-Based Controller
          Management Features Web-based GUI,
          DHCP Client,
          Cable Diagnostics,
          Automatic Device Discovery,
          Batch Configuration,
          Batch Firmware Upgrading,
          Unified Configuration
          Housing / case type desktop,
          metal
          Dimensions 11.6 × 5.5 × 1.7 in (294× 140 × 44 mm)
          Operating temperature -5°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100-240 V~50/60 Hz
          Certificates CE,
          FCC,
          RoHS
          Package Contents ES216G,
          Power Cord,
          Mounting Brackets,
          Screws,
          Installation Guide,
          Resource CD,
          Rubber Feet
          System Requirements Microsoft® Windows® for running Utility
          Warranty 5 years
          Manufacturer TP-Link
          TP-LINK
          Smart switch, 16x 10/100/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link ES216G)
          Net Price: 62,60 EUR
          product card»
          #09592

          Smart switch, 24x 10/100/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link ES224G)

          • 24× 10/100/1000Mbps RJ45 ports
          • Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
          • Centralized Cloud Management via the web or the Omada app†
          • Automatic Loop Prevention, VLAN, and IGMP Snooping
          • Fanless design for silent operation
          • Durable metal casing and desktop/rack mounting design
          Standards IEEE 802.3i,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3af,
          IEEE 802.3x,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 24x 10/100/1000 Mbps RJ-45
          Switching Capacity 48Gbps
          Packet Forwarding Rate 35,7 Mpps
          Mac Address Table 8K
          Jumbo Frame 15 KB
          Packet Buffer Memory 4 Mb
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Quality of Service Support Port-Based/802.1p/DSCP priority,
          Support 4 priority queues,
          Rate Limit,
          Storm Control
          L2 Features IGMP Snooping V1/V2/V3,
          Static Link Aggregation,
          Port Mirroring,
          Cable Diagnostics,
          Loop Prevention,
          PoE Auto Recovery,
          Extend Mode
          VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs),
          MTU/Port/Tag VLAN
          Management
          Omada App Yes. Requires the use of Omada Hardware Controller,
          Omada Cloud-Based Controller,
          or Omada Software Controller.
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller,
          Omada Software Controller
          Cloud Access Yes. Requires the use of Omada Hardware Controller,
          Omada Cloud-Based Controller,
          or Omada Software Controller.
          Zero-Touch Provisioning Yes. Requires the use of Omada Cloud-Based Controller
          Management Features Web-based GUI,
          DHCP Client,
          Cable Diagnostics,
          Automatic Device Discovery,
          Batch Configuration,
          Batch Firmware Upgrading,
          Unified Configuration
          Housing / case type desktop,
          metal
          Dimensions 11.6 × 5.5 × 1.7 in (294× 140 × 44 mm)
          Operating temperature -5°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100-240 V~50/60 Hz
          Certificates CE,
          FCC,
          RoHS
          Package Contents ES224G,
          Power Cord,
          Mounting Brackets,
          Screws,
          Installation Guide,
          Resource CD,
          Rubber Feet
          System Requirements Microsoft® Windows® for running Utility
          Warranty 5 years
          Manufacturer TP-Link
          TP-LINK
          Smart switch, 24x 10/100/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link ES224G)
          Net Price: 83,50 EUR
          product card»
      • » GIGABIT ETHERNET / L2 MANAGED SWITCHES
          #09368

          Managed switch, 8x 10/100/1000 RJ-45, 2x 100/1000 SFP, 2x Combo Gigabit, 19" (Edge-core ECS4100-12T)

          • Performance and Scalability
          • Continuous Availability
          • Comprehensive QoS
          • Robust Multicast Control
          • IPv6 Support
          • Reliability and Energy Efficiency
          • Enhanced Security
          • Superior Management
          • Virtual Private Networks
          Standards IEEE 802.3 100Base-FX,
          IEEE 802.3z 1000BASE-SX/LX/LHX/ZX
          Copper ports 8x 10/100/1000 Mbps RJ-45
          SFP ports 2x 100/1000 SFP
          Additional ports 1× RJ45 Console port,
          2x 10/100/1000 Combo ports
          Software features
          Quality of Service 8 hardware queues per port,
          IEEE 802.1p CoS,
          IP Precedence,
          DSCP,
          Strict Priority,
          Weighted Round Robin,
          Strict + WRR,
          Ingress policy map,
          Egress policy map,
          Rate Limiting (GE Resolution 64Kbps ~ 1.000Mbps
          L2 Features Tri-speed (10/100/1000BASE-T) copper interfaces,
          Auto-negotiation for port speed and duplex mode,
          Auto MDI/MDI-X,
          100 M/1 G fiber interfaces,
          IEEE 802.3 100BASE-FX,
          IEEE 802.3z (1000BASE-SX/LX/LHX/ZX) transceivers,
          Transceiver-threshold current/rx-power/temperature/tx-power/voltage/high-low alarm and warning,
          Digital Diagnostic Monitoring on SFP port only,
          IEEE 802.3x for full-duplex mode,
          Back-pressure for half-duplex mode,
          Jumbo frames- 12 KB,
          Broadcast/Multicast/Unknown Unicast Storm Control,
          IEEE 802.1D Spanning Tree Protocol,
          IEEE 802.1w Rapid Spanning Tree Protocol,
          IEEE 802.1s Multiple Spanning Tree Protocol (64 instances),
          Spanning-tree restricted-tcn,
          Spanning-tree tc-prop-stop - Stops propagation of topology change information,
          BPDU Guard,
          BPDU Filtering,
          Root Guard,
          BPDU Transparent,
          Loopback Detection,
          Non-Spanning Tree Loopback detection,
          Sub 50 msec convergence (ECS4100-12PH/28P/52P/28TC only),
          Non-revertive operation mode,
          Multiple-ring network,
          Selective Q-in-Q,
          VLAN Translation,
          L2 Protocol tunneling (xSTP/CDP/VTP & PVST+/LLDP),
          CDP/PVST+ Filtering,
          Static Trunk,
          IEEE 802.3ad (LACP),
          16 trunk groups up to 8 GE ports per group,
          Load Balancing (SA+DA/SA/DA/SIP+DIP/SIP/DIP),
          IGMP v1/v2/v3 Snooping,
          IGMP Proxy Reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier,
          IGMP mrouter-forward mode ,
          IGMP router-alert-option-check ,
          IGMP router-port-expire-time ,
          IGMP tcn-flood,
          IGMP tcn-query-solicit,
          IGMP unregistered-data-flood,
          MVR supports 5 multicast VLANs,
          Port mirroring,
          Remote port mirror (RSPAN)
          VLAN Supports 4K VLAN,
          Port-based VLAN,
          IEEE 802.1Q VLAN,
          GVRP (256 VLAN),
          IEEE 802.1v protocol-based VLAN,
          IP Subnet-based VLAN,
          MAC-based VLAN,
          Traffic Segmentation
          IPv6 Support IPv4/IPv6 Dual Protocol stack,
          IPv6 Address Types Stack (Unicast),
          Duplicate address,
          Address resolution,
          Unreachable neighbor detection,
          Stateless auto-configuration,
          Manual configuration,
          Remote IPv6 ping,
          IPv6 Telnet support,
          HTTP over IPv6,
          SNMP over IPv6,
          IPv6 Syslog support,
          IPv6 TFTP support,
          IPv6 MLD filter and throttling,
          IPv6 ND snooping,
          MLD Snooping v1/v2,
          IPv6 source guard,
          DHCPv6 snooping,
          MVR6
          Security IEEE 802.1X port based and MAC based authentication,
          Dynamic VLAN Assignment,
          Dynamic QoS assignment,
          MAC authentication,
          Web authentication,
          Voice VLAN,
          Guest VLAN,
          L2/L3/L4 Access Control List,
          MAC Access control list,
          IP standard access control list,
          IP extended access control list,
          DHCP Snooping,
          DHCP Option 82,
          DHCP Option 82 Relay,
          IP Source Guard,
          IPv6 ACL,
          Port security,
          PPPoE IA,
          Dynamic ARP Inspection,
          CPU guard,
          CPU/Memory threshold and alarm,
          echo-chargen,
          smurf,
          tcp-flooding,
          tcp-null-scan,
          tcp-syn-fin-scan,
          tcp-xmas-scan,
          udp-flooding,
          win-nuke,
          Login Security,
          RADIUS authentication,
          RADIUS accounting,
          TACACS + authentication,
          TACACS + accounting,
          TACACS + authorization,
          Management Interface Access Filtering (SNMP/Web/Telnet),
          SSH (v1.5/v2.0) for security Telnet,
          SSL for HTTPS,
          SNMPv3
          Management
          Management Features CLI via console port or Telnet,
          Web management,
          SNMP (v1/v2c/v3),
          IP clustering (32 members),
          Firmware upgrade via TFTP/HTTP/FTP/SFTP server,
          Dual images,
          Multiple configuration files,
          Configuration file upload/download via TFTP/HTTP/FTP/SFTP server,
          Firmware auto upgrade,
          RMON (groups 1/2/3 and 9),
          BOOTP (DHCP client for IP address assignment),
          DHCP dynamic provision option (66/67),
          SNTP/NTP,
          DNS client,
          Event/Error Log,
          Syslog,
          SMTP,
          Supports LLDP (802.1ab),
          sFlow (v4/v5),
          Cable diagnostics,
          Topology management,
          Performance management,
          Configuration management,
          Event management,
          SNMP management
          Switching capacity [Gbps] 24
          Packet Forwarding Rate 17.85 Mpps
          MAC Address Table 16K
          Jumbo Frame 12 KB
          Housing / case type Rack Mountable
          Dimensions 18 × 16.4 × 3.75 cm
          Weight 804 g
          Operating temperature 0°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100~240VAC 50/60Hz (Rear panel)
          Max Power Consumption 16 W
          Certificates FCC Class A,
          CE,
          BSMI,
          Safety Compliance (CB/UL)
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 8x 10/100/1000 RJ-45, 2x 100/1000 SFP, 2x Combo Gigabit, 19" (Edge-core ECS4100-12T)
          for special orders only
          Net Price: 254,00 EUR
          product card»

top

Page 1 of 12
