#09661
LTE Mobile Hotspot Wi-Fi, 600Mbps (TP-Link M7750)
- LTE-Advanced cat12 supported with up to 600 Mbps download and 150 Mbps upload speeds
- Supports up to 32 devices simultaneously
- Selectable 300 Mbps at 2.4GHz or 867 Mbps at 5GHz dual band Wi-Fi
- All useful information at a glance with screen display
- 3280 mAh battery for up to 15 hours of working
- Equipped with a micro SD card slot for up to 2TB of optional storage
- Easy management with the tpMiFi App
| HARDWARE FEATURES | |
|---|---|
| Interface |
1 USB-C port for power supply, nanoSIM Card Slot, Micro SD card Slot |
| Button |
Power On/Off Button, Reset Button, Menu |
| Display | 1.44 inch TFT |
| Wireless Standards | IEEE 802.11a/b/g/n/ac 300Mbps at 2.4GHz or 867Mbps at 5GHz |
| Network Type |
FDD-LTE- B1/B3/B7/B8/B20(2100/1800/2600/900/800MHz), TDD-LTE- B38/B40/B41 (2600/2300/2500MHz), DC-HSPA+/HSPA/UMTS- B1/B8(2100/900MHz), EDGE/GPRS/GSM- 850/900/1800/1900MHz |
| Data Rates |
DL- up to 600Mbps, UL- up to 150Mbps |
| Antenna | Internal Antenna |
| Power Supply | Internal 3280mAh Rechargeable Battery |
| Dimensions ( W x D x H ) | 4.5 × 2.5 × 0.7 in. (114 × 64 × 19mm) |
| Micro SD Card Reader | up to 2TB |
| WIRELESS FEATURES | |
| Frequency | 2.4GHz & 5GHz |
| EIRP |
2,4G <20dbm, 5G <23dbm |
| Wireless Security |
Support WPA-PSK/WPA2-PSK, Wireless MAC Filtering, Enable/Disable SSID Broadcast |
| DHCP |
DHCP server, DHCP Client List |
| OTHERS | |
| Certification |
CE, FCC, RoHS |
| Package Contents |
600Mbps LTE-Advanced Mobile Wi-Fi M7750, USB-C Cable, 3280mAh Battery, Quick Installation Guide |
| System Requirements |
Windows 11/10/8/7/Vista/XP, Mac OS, Android, iOS |
#09758
LTE-Advanced Mobile Hotspot Wi-Fi (TP-Link M7400)
- LTE-Advanced cat6 supported with up to 300Mbps download and 50Mbps upload speeds
- Supports up to 32 devices simultaneously
- Selectable 300Mbps at 2.4GHz or 867Mbps at 5GHz dual band Wi-Fi
- 2100mAh battery for up to 8 hours of working
- Equipped with a micro SD card slot for up to 2TB of optional storage
- Easy management with the tpMiFi App
| HARDWARE FEATURES | |
|---|---|
| Interface |
1 USB-C port for power supply, nanoSIM Card Slot, Micro SD card Slot |
| Button |
Power On/Off Button, Menu Button |
| Wireless Standards | IEEE 802.11a/b/g/n/ac 300Mbps at 2.4GHz or 867Mbps at 5GHz |
| Network Type |
FDD-LTE B1/B3/B7/B8/B20(2100/1800/2600/900/800MHz), TDD-LTE B38/B40/B41 (2600/2300/2500MHz), DC-HSPA+/HSPA/UMTS B1/B8(2100/900MHz), EDGE/GPRS/GSM 850/900/1800/1900MHz |
| Data Rates |
DL- 300Mbps, UL- 50Mbps |
| Antenna | Internal Antenna |
| Power Supply | Internal 3000mAh Rechargeable Battery |
| Dimensions ( W x D x H ) | 4.5 × 2.5 × 0.7 in (114 × 64 × 17.7mm) |
| Micro SD Card Reader | up to 2TB |
| WIRELESS FEATURES | |
| Frequency | 2.4GHz & 5GHz |
| EIRP |
2,4G <20dbm, 5G <23dbm |
| Wireless Security |
Support WPA-PSK/WPA2-PSK, Wireless MAC Filtering, |
| DHCP |
DHCP server, DHCP Client List |
| OTHERS | |
| Certification |
CE, RoHS |
| Package Contents |
300Mbps LTE-Advanced Mobile Wi-Fi M740, USB-C Cable, 2100mAh Battery, Quick Installation Guide |
| System Requirements |
Windows 11/10/8/7/vista/XP, Mac OS, Android, iOS |
#09011
150Mbps Wireless access point, 5GHz, PoE (TP-Link CPE605)
- Up to 150Mbps on 5GHz wireless data rates
- 23dBi high-gain directional antenna and a dedicated metal reflector, ideal for long-distance application
- Excellent beam directivity, improved latency and noise cancellation
- Innovative snap-lock parts make for fast assembly and a sturdy structural design keeps CPE605 stable even in strong winds
- Durable IP65 weatherproof enclosure along with 15 kV ESD and 6 kV lightning protection ensures all-weather suitability
- TP-Link Pharos MAXtream TDMA technology improves throughput, capacity and latency performance
- Pharos Control gives administrators a free, centralized management system
- Passive PoE supports to allow flexible deployment and convenient installation
| Processor |
Qualcomm 560MHz CPU, MIPS 74Kc |
|---|---|
| Memory |
64MB DDR2 RAM, 8MB Flash |
| Standards |
IEEE 802.11a, IEEE 802.11n |
| Ports |
1 10/100Mbps Shielded Ethernet Port (LAN0, Passive PoE in), 1 Reset Button |
| Antenna Gain | 23dBi |
| Antenna Beamwidth |
7°(Azimuth), 10°(Elevation) |
| Wireless Configurations |
Pharos MAXtream TDMA Technology, 802.11a/n Modes, Selectable Channel Width 5/10/20/40MHz, Automatic Channel Selection, Transmission Power Control, Dynamic Frequency Selection (DFS), WDS Enable/Disable, SSID Broadcast Enable/Disable, Multi-SSID with VLAN Tagging (AP mode only), Distance/ACK Timeout Setting, Wireless MAC Address Filter, Long Range PtP |
| Security |
WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption |
| Wireless Advanced |
Beacon Interval/RTS Threshold/Fragmentation, Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia |
| Management |
Discovery and Remote Management via Pharos Control application, HTTP/HTTPS Web-based management, System Log, SNMP Agent(v2c), Ping Watch Dog, Dynamic DDNS, SSH Server |
| System Tools |
Wireless Signal Quality Indicators - Signal Strength/Noise/Transmit CCQ/CPU/Memory, Monitors - Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP, Spectrum Analyzer, Speed Test, Ping, Traceroute |
| Signal Rate |
Up to 150Mbps (40MHz, Dynamic), Up to 72.2Mbps (20MHz, Dynamic), Up to 36.1Mbps (10MHz, Dynamic), Up to 18.05Mbps (5MHz, Dynamic) |
| Dimensions | 350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.) |
| Power Supply |
Passive Power over Ethernet via LAN (+4,5pins; -7,8pins), Voltage range- 16-27VDC |
| Protection |
15KV ESD Protection, 6000V Lightning Protection |
| Enclosure |
Outdoor PC stabilized plastic, Weatherproof IP65 water and dust proof design |
| Package Contents |
Outdoor Wireless CPE, 24V 0.25A Passive PoE Adapter, Pole Mounting Kits, AC Power Cord, Installation Guide |
| Operating temperatures | -40°C ÷ 70°C |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~95% non-condensing |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ lub Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX lub Linux. We recommend you to use one of following Web browsers for an improved user experience Google Chrome, Safari, and Firefox. IE browsers are not recommended. |
| Certificates |
CE, FCC, RoHS, IPX5 |
| Warranty | 5 years |
| Manufacturer | Tp-Link |
1.0-02_large_1559628836496f.jpg?1737057893)
1.0-03_large_1559628850466d.jpg?1737057900)
#04680
300Mbps Outdoor Wireless Access Point, N300 (TP-Link EAP110-Outdoor)
- Built for outdoor Wi-Fi applications
- Up to 300Mbps Wi-Fi with 2x2 MIMO technology
- High transmission power and high gain antennas provide a long-range coverage area
- Durable, weatherproof enclosure to withstand fair and foul weather
- Passive PoE(Power over Ethernet) support and simple mounting design allow for flexible deployment and convenient installation
- Free Auranet Controller Software lets administrators easily manage hundreds of EAPs
- Captive portal provides a convenient method for guest authentication
| Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|---|---|
| Ports | Fast Ethernet (RJ-45) Port *1（Support Passive PoE） |
| Frequency range | 2,4GHz |
| Wireless Functions |
Multiple SSIDs (Up to 8 SSIDs), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Load Balance, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
| Wireless Security |
Captive Portal Authentication, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
| Antenna | 2*5dBi External Omni waterproof |
| Dimensions | 95 x 42,6 x 209 mm |
| Power | 24VDC / 0.6A Passive PoE Supply |
| Power Consumption | 6.3W |
| Mounting | Pole / Wall Mounting (Kits included) |
| Watch Dog | Yes |
| Operating Temperature | -30°C~65°C (-22℉~149℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
300Mbps Wireless N Outdoor Access Point, EAP110-Outdoor, Passive PoE Adapter, Power Cord, Mounting Kits, Waterproof Rubber Insert, Waterproof Antennas, Installation Guide |
| System Requirements | Microsoft Windows 10/8/7/Vista/XP |
| Certificates |
CE, FCC, RoHS |
| Warranty | 5 years |
#04679
300Mbps Outdoor Wireless Access Point, N300 (TP-Link EAP115-Wall)
- Easy-mount construction allows installation into any standard EU-type data wall-box
- Compact, low-profile design fits discreetly with any existing interior style
- Free Auranet Controller Software enables administrators to easily manage hundreds of EAPs
- Support Power over Ethernet (802.3af) for convenient and affordable installation
- Enterprise class Wi-Fi security helps to decrease network security threats
- Captive portal provides one convenient method of authentication for Wi-Fi guests
- Supports management vlan for an enhanced network management
| Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|---|---|
| Ports | Fast Ethernet (RJ-45) Port *2 |
| Frequency range | 2,4GHz |
| Wireless Functions |
Multiple SSIDs (Up to 8 SSIDs), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Load Balance, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
| Wireless Security |
Captive Portal Authentication, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
| Antenna | Internal 2*1.8dBi Omni |
| Dimensions | 86,8*86,8*30,2 mm (3,4×3,4×1,2 in) |
| Power | PoE (IEEE 802.3af) |
| Power Consumption | 2.8W |
| Mounting | Wall Mounting |
| Watch Dog | Yes |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
EAP115-Wall, Power Adapter, Mounting Kits, Installation Guide |
| System Requirements | Microsoft Windows 10/8/7/Vista/XP |
| Certificates |
CE, FCC, RoHS |
| Warranty | 5 years |
#08941
300Mbps Wireless access point, 2.4GHz (TP-LINK CPE210)
| Processor |
Qualcomm Atheros 560MHz CPU, MIPS 74Kc |
|---|---|
| Memory |
64MB DDR2 RAM, 8MB Flash |
| Standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ports |
1 10/100Mbps Shielded Ethernet Port (LAN0, Passive PoE in), 1 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE |
| Passthrough), 1 Grounding Terminal, 1 Reset Button | |
| Wireless Configurations |
Pharos MAXtream TDMA Technology, 802.11b/g/n Modes, Selectable Channel Width 5/10/20/40MHz, Automatic Channel Selection, Transmission Power Control, Dynamic Frequency Selection (DFS), WDS Enable/Disable, SSID Broadcast Enable/Disable, Multi-SSID with VLAN Tagging (AP mode only), Distance/ACK Timeout Setting, Wireless MAC Address Filter |
| Security |
WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption |
| Wireless Advanced |
Beacon Interval/RTS Threshold/Fragmentation, Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia |
| Management |
Discovery and Remote Management via Pharos Control application, HTTP/HTTPS Web-based management, System Log, SNMP Agent(v2c), Ping Watch Dog, Dynamic DDNS, SSH Server |
| System Tools |
Wireless Signal Quality Indicators - Signal Strength/Noise/Transmit CCQ/CPU/Memory, Monitors - Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP, Spectrum Analyzer, Speed Test, Ping, Traceroute |
| Signal Rate |
Up to 300Mbps (40MHz, Dynamic), Up to 144.4Mbps (20MHz, Dynamic), Up to 72.2Mbps (10MHz, Dynamic), Up to 36.1Mbps (5MHz, Dynamic) |
| Receiver sensitivity |
802.11b 11M@ -95dBm, 5,5M@ -96dBm, 2M@ -96dBm, 1M@ -96dBm 802.11g 54M@ -79dBm 48M@ -80dBm 36M@ -84dBm 6-24M@ -88dBm, 802.11n MCS15 -76dBm, MCS14 -78dBm, MCS13 -80dBm, MCS12 -84dBm, MCS11 -87dBm, MCS10 -91dBm, MCS9 -93dBm, MCS8 -96dBm, MCS7 -76dBm, MCS6 -78dBm, MCS5 -80dBm, MCS4 -84dBm, MCS3 -87dBm, MCS2 -91dBm, MCS1 -93dBm, MCS0 -96dBm |
| Antenna | Built-in 9dBi 2x2 Dual-polarized Directional Antenna |
| Beam width | 65° (H-Plane) / 35° (E-Plane) |
| Dimensions | 224 x 79 x 60 mm |
| Power Consumption |
10.5 Watts Max (When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable) |
| Power Supply |
Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins), Voltage range 16-27VDC |
| Protection |
15KV ESD Protection, 6000V Lightning Protection |
| Enclosure |
Outdoor ASA stabilized plastic material, IPX5 waterproof Certification |
| Package Contents |
Outdoor Wireless CPE, 24V 1A Passive PoE Adapter, Pole Mounting Straps, AC Power Cord, Installation Guide |
| Operating temperatures | -30°C ÷ 70°C |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC OS, NetWare, UNIX or Linux. |
| Certificates |
CE, FCC, RoHS, IPX5 |
| Warranty | 5 years |
| Manufacturer | Tp-Link |
#08940
300Mbps Wireless access point, 5GHz (TP-LINK CPE510)
| Processor |
Qualcomm Atheros Enterprise AR9350B 560MHz CPU, MIPS 74Kc |
|---|---|
| Memory |
64MB DDR2 RAM, 8MB Flash |
| Standards |
IEEE 802.11a, IEEE 802.11n |
| Ports |
1 10/100Mbps Shielded Ethernet Port (LAN0, Passive PoE in), 1 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE Passthrough), 1 Grounding Terminal, 1 Reset Button |
| Wireless Configurations |
Pharos MAXtream TDMA Technology, 802.11a/n Modes, Selectable Channel Width 5/10/20/40MHz, Automatic Channel Selection, Transmission Power Control, Dynamic Frequency Selection (DFS), WDS Enable/Disable, SSID Broadcast Enable/Disable, Multi-SSID with VLAN Tagging (AP mode only), Distance/ACK Timeout Setting, Wireless MAC Address Filter |
| Security |
WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption |
| Wireless Advanced |
Beacon Interval/RTS Threshold/Fragmentation, Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia |
| Management |
Discovery and Remote Management via Pharos Control application, HTTP/HTTPS Web-based management, System Log, SNMP Agent(v2c), Ping Watch Dog, Dynamic DDNS, SSH Server |
| System Tools |
Wireless Signal Quality Indicators - Signal Strength/Noise/Transmit CCQ/CPU/Memory, Monitors - Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP, Spectrum Analyzer, Speed Test, Ping, Traceroute |
| Signal Rate |
Up to 300Mbps (40MHz, Dynamic), Up to 144.4Mbps (20MHz, Dynamic), Up to 72.2Mbps (10MHz, Dynamic), Up to 36.1Mbps (5MHz, Dynamic) |
| Receiver sensitivity |
802.11a 54M@ -75dBm 48M@ -76dBm 36M@ -83dBm 6-24M@ -95dBm, 802.11n MCS15 -73dBm, MCS14 -74dBm, MCS13 -76dBm, MCS12 -80dBm, MCS11 -83dBm, MCS10 -88dBm, MCS9 -90dBm, MCS8 -93dBm, MCS7 -73dBm, MCS6 -74dBm, MCS5 -76dBm, MCS4 -80dBm, MCS3 -83dBm, MCS2 -88dBm, MCS1 -90dBm, MCS0 -93dBm |
| Antenna | Built-in 13dBi 2x2 Dual-polarized Directional Antenna |
| Beam width | 45° (H-Plane) / 30° (E-Plane) |
| Dimensions | 224 x 79 x 60 mm |
| Power Consumption |
13 Watts Max (When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable) |
| Power Supply |
Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins), Voltage range 16-27VDC |
| Protection |
15KV ESD Protection, 6000V Lightning Protection |
| Enclosure |
Outdoor ASA stabilized plastic material, IPX5 waterproof Certification |
| Package Contents |
Outdoor Wireless CPE, 24V 1A Passive PoE Adapter, Pole Mounting Straps, AC Power Cord, Installation Guide |
| Operating temperatures | -30°C ÷ 70°C |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC OS, NetWare, UNIX or Linux. |
| Certificates |
CE, FCC, RoHS, IPX5 |
| Warranty | 5 years |
| Manufacturer | Tp-Link |
#04661
300Mbps Wireless Access Point, N (TP-Link EAP110)
- EAP Controller Software enables administrators to easily manage hundreds of EAPs
- Supports passive PoE for convenient installation up to 100meters
- Ceiling mounting design with chassis make it easy to deploy on a wall or ceiling
- Captive portal provides one convenient method of authentication for Wi-Fi guests
- Multi-SSID divides multiple wireless networks for different users
- Enterprise class Wi-Fi security help to decrease network security threats
| Standards | IEEE 802.11n/g/b |
|---|---|
| Ports | Fast Ethernet (RJ-45) Port *1 (Support Passive PoE) |
| Frequency range | 2.4-2.4835GHz |
| Signal Rate |
11n Up to 300Mbps(dynamic), 11g Up to 54Mbps(dynamic), 11b Up to 11Mbps(dynamic) |
| EIRP |
FCC <26dBm(2.4GHz), CE <20dBm |
| Wireless Functions |
Multiple SSIDs (Up to 16 SSIDs, 8 for each band), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Airtime Fairness, Beamforming, Band Steering, Load Balance, Rate Limit, Link Aggregation, Reboot Schedule, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
| Wireless Security |
Captive Portal Authentication, Access Control, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
| EAP Controller Software | Yes |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| Telnet | Yes |
| Web-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Antenna | Internal 2* 3dBi Omni |
| Dimensions | 7.1 x 7.1 x 1.9in. (180*180*47.5mm) |
| Power | 24VDC / 1A Passive PoE Supply |
| Power Consumption | 7.7 W |
| Mounting | Ceiling /Wall Mounting (Kits included) |
| Physical Security Lock | Kensington Lock Slot |
| Watch Dog | Yes |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
Wireless Access Point EAP110, Passive PoE Adapter, Power Adapter, Mounting Kits, Installation Guide |
| System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
| Certificates |
CE, FCC, RoHS |
| Warranty | 5 years |
#04660
300Mbps Wireless Access Point, N (TP-Link EAP115)
- Free Auranet Controller Software enables administrators to easily manage hundreds of EAPs
- The user-friendly Cluster Mode allows manage up to 24 (EAP115) without requiring any extra hardware or software
- Supports Power over Ethernet (802.3af) for convenient and affordable installation
- Simple mounting design for easy attachment to a wall or ceiling
- Captive portal provides one convenient method of authentication for Wi-Fi guests
- Enterprise class Wi-Fi security help to decrease network security threats
- Multi-SSID divides multiple wireless networks for different user types
| Standards | IEEE 802.11n/g/b |
|---|---|
| Ports | Fast Ethernet (RJ-45) Port *1 (ETH1 Support IEEE802.3af PoE) |
| Frequency range | 2.4-2.4835GHz |
| Signal Rate |
11n Up to 300Mbps(dynamic), 11g Up to 54Mbps(dynamic), 11b Up to 11Mbps(dynamic) |
| EIRP |
FCC <26dBm(2.4GHz), CE <20dBm |
| Wireless Functions |
Multiple SSIDs (Up to 16 SSIDs, 8 for each band), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Airtime Fairness, Beamforming, Band Steering, Load Balance, Rate Limit, Link Aggregation, Reboot Schedule, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
| Wireless Security |
Captive Portal Authentication, Access Control, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
| EAP Controller Software | Yes |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| Telnet | Yes |
| Web-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Antenna | Internal 2* 3dBi Omni |
| Dimensions | 7.1 x 7.1 x 1.9in. (180*180*47.5mm) |
| Power | PoE or External 12VDC / 1A Power Supply |
| Power Consumption | 5 W |
| Mounting | Ceiling /Wall Mounting (Kits included) |
| Physical Security Lock | Kensington Lock Slot |
| Watch Dog | Yes |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
Wireless Access Point EAP115, Power Adapter, Mounting Kits, Installation Guide |
| System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
| Certificates |
CE, FCC, RoHS |
| Warranty | 5 years |
#09703
Outdoor Wireless Bridge (TP-Link EAP100-Bridge KIT)
- Up to 1640 ft (500 m)Wi-Fi transmission
- Equipped with Omada SmartBridging: Our unique design for the most effortless and easy bridge setup ever.
- Plug-and-Play Preconfigured Kit: Preconfigured for instant auto-pairing, the bridges deliver instant connectivity right out of the box. Simply power on and go. Ideal for quick deployments.
- App-Guided Alignment: Visualized App-Guided Alignment for long-distance setups and Instant Speed Testing for installation verification.
- Flexible Power Supply: 802.3af PoE, 24V /48V Passive PoE, and 12V DC (compatible with TP-Link solar power supply systems).
- 3× Fast Ethernet Ports: Connects more cameras and devices without an extra switch.
- Built for Tough Outdoor Conditions: Features an IP65 weatherproof enclosure and operating range of -40℉ to +158 ℉.
- Remote Monitoring & Management: Choose Standalone mode or Omada SDN mode for remote centralized management via Web UI or app.
| Standards | IEEE 802.11b/g/n |
|---|---|
| Ports | 3x 10/100 Mbps Ethernet Ports |
| Frequency range | 2.4 GHz |
| Signal Rate | 2.4GHz Up to 300Mbps |
| Wireless Functions |
Mesh, MU-MIMO 5G 2x2 MU-MIMO DL, Load Balance, Beamforming, Seamless Roaming(802.11r), Airtime Fairness, Multiple SSIDs 8, Wireless Statistics, Wireless Schedule, Reboot Schedule, RADIUS Accounting, MAC Authentication, Static IP/Dynamic IP |
| Wireless Security |
VLAN, Access Control, Rogue AP Detection, Captive Portal Authentication, Maximum number of MAC Filter 4,000, WPA-Personal/Enterprise, WPA2-Personal/Enterprise |
| Omada App | Yes |
| Restore & Backup | Yes |
| Firmware update via Web | Yes |
| NTP | Yes |
| Centralized Management |
Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller, Omada Cloud-Based Controller |
| Cloud Access |
Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller. |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP |
v1, v2c, v3 |
| SSH | Yes |
| Web-based Management | Yes |
| Weatherproof Enclosure | IP65 |
| Dimensions | 3.1 x 2.4 x 8.8 in (79 × 60 × 224 mm) |
| Power |
12V DC, 802.3af PoE, 24V Passive PoE / 48V Passive PoE (Passive PoE Adapter Included - For Dry Indoor Use Only) |
| Power Consumption | 4.8 W |
| Antenna Type |
Internal 2×2 Dual-polarized directional MIMO antennas, 2.4 GHz 8.0 dBi, Horizontal 70°, Vertical 70° |
| Mounting | Pole mounting (Accessories included) |
| Operating Temperature | -40°C~40°C (-40℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Certificates |
CE, FCC, RoHS |
| Warranty | 5 years |
Page 2 of 7
|
