MENU#06285
Wireless access point Ubiquiti PowerBeam M5 MIMO 5GHz (Ubiquiti PBE-M5-300-ISO-EU)
| Standards | IEEE 802.11a/n |
|---|---|
| Ports | 1x 10/100 Mbps RJ-45 |
| Chipset | Atheros MIPS 74KC, 560 MHz |
| Operating memory | 64 MB DDR2 |
| Flash memory | 8 MB |
| Antenna | build-in, 22 dBi |
| Range | 20+ km |
| VSWR | 1.5 |
| Dimensions | 364 x 364 x 276 mm (14.33 x 14.33 x 10.87") |
| Weight | 2.55 kg (5.62 lb) |
| Mounting | mast or wall with the aid of antenna wall support |
| Max. power consumption | 6 W |
| Power | 24V, 0.5A PoE, Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Operating temperatures | -40°C ÷ 70°C |
| Operating humidity | 5% ÷ 95%, Non-condensing |
| Salt Fog Test | IEC 68-2-11 (ASTM B117), Equivalent MIL-STD-810 G Method 509.5 |
| Vibration Test | IEC 68-2-6 |
| Temperature Shock Test | IEC 68-2-14 |
| UV Test | IEC 68-2-5 at 40° C (104° F), Equivalent ETS 300 019-1-4 |
| Wind-Driven Rain Test | ETS 300 019-1-4, Equivalent MIL-STD-810 G Method 506.5 |
| Manufacturer | Ubiquiti |
TAGS:
PoE
| * For special orders only
Net Price: 83,70 EUR Unit: pcs
|
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
