| Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2,4 GHz |
|---|---|
| Ports | 3 x 10/100/1000 Mb/s ports per Halo unit (WAN/LAN auto-sensing) |
| Button | 1 Reset button |
| Frequency range | 2.4 GHz and 5 GHz |
| Signal Rate |
574 Mbps on 2.4 GHz, 2402 Mbps on 5 GHz |
| EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
| Wireless Security | WPA2-PSK + AES |
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
| Mesh protocol | 802.11k/v |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
| Management |
Access Control, Local Management, Remote Management |
| DHCP |
Server, Address Reservation, DHCP Client List |
| Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
| Protocols |
IPv4, IPv6 |
| Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
| Dimensions | 5 × 3.2 × 3.3 in (128 × 81 × 83,7 mm) |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
3 Halo H80X units, 3 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
| Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2,4 GHz |
|---|---|
| Ports | 1× 2.5 Gbps Port + 2× 1 Gbps Ports per Halo unit (WAN/LAN auto-sensing) |
| Button | 1 Reset button |
| Frequency range | 2.4 GHz and 5 GHz |
| Signal Rate |
574 Mbps on 2.4 GHz, 2402 Mbps on 5 GHz |
| EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
| Wireless Security | WPA2-PSK + AES |
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
| Mesh protocol | 802.11k/v |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
| Management |
Access Control, Local Management, Remote Management |
| DHCP |
Server, Address Reservation, DHCP Client List |
| Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
| Protocols |
IPv4, IPv6 |
| Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
| Dimensions | 5 × 3.2 × 3.3 in (128 × 81 × 83,7 mm) |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
2 Halo H85X units, 2 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
| Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2,4 GHz |
|---|---|
| Ports | 1× 2.5 Gbps Port + 2× 1 Gbps Ports per Halo unit (WAN/LAN auto-sensing) |
| Button | 1 Reset button |
| Frequency range | 2.4 GHz and 5 GHz |
| Signal Rate |
574 Mbps on 2.4 GHz, 2402 Mbps on 5 GHz |
| EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
| Wireless Security | WPA2-PSK + AES |
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
| Mesh protocol | 802.11k/v |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
| Management |
Access Control, Local Management, Remote Management |
| DHCP |
Server, Address Reservation, DHCP Client List |
| Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
| Protocols |
IPv4, IPv6 |
| Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
| Dimensions | 5 × 3.2 × 3.3 in (128 × 81 × 83,7 mm) |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
3 Halo H85X units, 3 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
| Standards |
IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11n/b/g 2,4 GHz |
|---|---|
| Ports |
1x 10/100/1000 Mbps RJ-45 (LAN), 1x 10/100/1000 Mbps RJ-45 (WAN), 1 port USB 2.0 |
| Frequency range | 2,4GHz and 5GHz |
| Modulation |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM |
| Operating modes | AP Router |
| Max. speed |
5 GHz@ 1201 Mb/s (802.11ax), 2,4 GHz@ 300 Mb/s (802.11n) |
| Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| WLAN security |
64/128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
| WAN Type |
Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
| Management |
Access Control, Local Management, Remote Management |
| DHCP |
Server, DHCP Client List |
| Port Forwarding |
Virtual Server, UPnP, DMZ |
| Dynamic DNS |
DynDns, NO-IP |
| Access Control |
Parental Controls, Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security |
DoS, SPI Firewall IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding |
| Protocols |
IPv4, IPv6 |
| Guest Network |
1× 2.4 GHz Guest Network, 1× 5 GHz Guest Network |
| Dimensions | 4.09 × 3.54 × 1.10 in (104 × 90 × 28 mm) |
| Operating temperatures | 0°C ÷ 40°C |
| Operating humidity |
10% ÷ 90%, non-condensing |
| Power | 12 V DC / 1,5 A |
| Certificates |
CE, RoHS |
| Manufacturer | TP-Link |
| HARDWARE FEATURES: | |
|---|---|
| Standards and Protocols |
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Interface |
4 10/100/1000Mbps LAN Ports, 1 10/100/1000Mbps WAN Port |
| Button |
WPS Button, Wireless On/Off Button, Reset Button, On/Off Button |
| External Power Supply | 12V/1A |
| Dimensions (W X D X H) | 230 × 144 × 35 mm (9,1 × 5,7 × 1,4 in.) |
| Antenna | 3 external detachable dual band antennas (RP-SMA) |
| WIRELESS FEATURES: | |
| Frequency | 2.4GHz & 5GHz |
| Signal Rate |
5GHz Up to 867Mbps, 2.4GHz Up to 300Mbps |
| EIRP | CE EIRP <20dBm(2.4GHz); <23dBm(5GHz) |
| Reception Sensitivity |
5GHz - 11a 6Mbps-93dBm, 11a 54Mbps -78dBm, 11ac HT20 -69dBm, 11ac HT40 -65dBm, 11ac HT80 -62dBm, 2.4GHz - 11g 54M -78dBm, 11n HT20 -74dBm, 11n HT40 -71dBm |
| Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Wireless Security | 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption |
| SOFTWARE FEATURES: | |
| WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP (Dual Access)/L2TP (Dual Access)/BigPond |
| DHCP |
Server, Client, DHCP Client List, Address Reservation |
| Quality of Service |
WMM, Bandwidth Control |
| Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS |
DynDns, Comexe, NO-IP |
| VPN Pass-Through |
PPTP, L2TP, IPSec |
| Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
| USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
| Management |
Access Control, Local Management, Remote Management |
| Guest Network | 2.4GHz guest network × 1, 5GHz guest network × 1 |
| OTHERS: | |
| Certification |
CE, FCC, IC, RoHS |
| Package Contents |
Wireless Router Archer C6, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide |
| System Requirements |
Microsoft® Windows® 98SE, NT, 2000, XP, Vista™, Windows 7 or Windows 8, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
| Warranty | 2 years limited warranty. Advanced replacement service is available. |
| Manufacturer | TP-Link |
| HARDWARE FEATURES: | |
|---|---|
| Standards and Protocols |
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Interface |
4 10/100Mbps LAN Ports, 1 10/100Mbps WAN Port |
| Button | WPS/Reset Button |
| External Power Supply | 12VDC / 1A |
| Dimensions (W X D X H) | 4.7 × 4.7 × 1.1 in (120 × 120 × 27.9 mm) |
| Antenna | 4 Antennas |
| WIRELESS FEATURES: | |
| Frequency | 2.4GHz & 5GHz |
| Signal Rate |
5GHz Up to 867Mbps, 2.4GHz Up to 400Mbps |
| EIRP |
CE <20dBm(2,4GHz), <23dBm(5GHz), FCC <30dB |
| Wireless Functions |
Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption |
| SOFTWARE FEATURES: | |
| WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP (Dual Access)/L2TP (Dual Access)/BigPond |
| DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP relay |
| Quality of Service |
WMM, Bandwidth Control |
| Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS |
DynDns, Comexe, NO-IP |
| VPN Pass-Through |
PPTP, L2TP, IPSec Passthrough |
| Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
| USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
| Management |
Access Control, Local Management, Remote Management |
| Guest Network | 2.4GHz guest network × 1, 5GHz guest network × 2 |
| OTHERS: | |
| Certification |
CE, FCC, IC, RoHS |
| Package Contents |
Archer C64, Power supply unit, Quick Installation Guide, Ethernet Cable |
| System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser |
| Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
| Manufacturer | TP-Link |
| HARDWARE FEATURES: | |
|---|---|
| Standards and Protocols |
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Interface |
4 10/100/1000Mbps LAN Ports, 1 10/100/1000Mbps WAN Port, |
| Button |
WPS/Reset Button, Wireless On/Off Button, Power On/off Button |
| External Power Supply | 12VDC / 1A |
| Dimensions (W X D X H) | 8.5 × 4.6 × 1.26 in (215 × 117 × 32 mm) |
| Antenna | 4 Fixed Omni Directional Antennas |
| WIRELESS FEATURES: | |
| Frequency | 2.4GHz & 5GHz |
| Signal Rate |
5GHz Up to 1300Mbps, 2.4GHz Up to 600Mbps |
| EIRP | <20dBm(EIRP) |
| Wireless Functions |
Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption |
| SOFTWARE FEATURES: | |
| WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP (Dual Access)/L2TP (Dual Access)/BigPond |
| DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP relay |
| Quality of Service |
WMM, Bandwidth Control |
| Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS |
DynDns, Comexe, NO-IP |
| VPN Pass-Through |
PPTP, L2TP, IPSec Passthrough |
| Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
| USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
| Management |
Access Control, Local Management, Remote Management |
| Guest Network | 2.4GHz guest network × 1, 5GHz guest network × 2 |
| OTHERS: | |
| Certification |
CE, FCC, IC, RoHS |
| Package Contents |
Archer C80, 2 antennas, Power supply unit, Quick Installation Guide, Ethernet Cable |
| System Requirements |
Microsoft® Windows® XP, Vista™, Windows 7,8,10, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
| Warranty | 2 years limited warranty. Advanced replacement service is available. |
| Manufacturer | TP-Link |
| HARDWARE FEATURES: | |
|---|---|
| Interface |
1 10/100Mbps WAN/LAN Port, 1 USB Port, 1 Reset Button, 1 Mode Switch, 1 WPS Button |
| Wireless Standards |
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2,4GHz |
| Dimensions ( W x D x H ) | 74x67x22mm (2,91x2,64x0,87 in.) |
| External Power Supply | 5V/2A |
| Antenna Type | On-Board |
| WIRELESS FEATURES: | |
| Frequency | 2,4GHz and 5GHz |
| Signal Rate | 5GHz - Up to 433Mbps(Only with 11AC Wireless Adapter); Up to 150Mbps with 11N Wireless Adapter 2.4GHz - Up to 300Mbps |
| EIRP |
<20dBm(2,4GHz), <23dBm(5GHz) |
| Reception Sensitivity |
11a 54M -76dBm; 11ac VHT20 MCS8 -70dBm; 11ac VHT40 MCS9 -65.5dBm; 11ac VHT80 MCS9 -61.5dBm, 2,4GHz 11g 54M -76dBm11n; HT20 MCS7 -74dBm; 11n HT40 MCS7 -71dBm |
| Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge, WMM,, Wireless Statistics |
| Wireless Security |
64/128 WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| SOFTWARE FEATURES: | |
| WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP/L2TP |
| DHCP |
Server, Client, DHCP Client List,, Address Reservation |
| Quality of Service |
WMM, Bandwidth Control |
| Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS |
DynDns, Comexe, NO-IP |
| VPN Pass-Through |
PPTP, L2TP, IPSec (ESP Head) |
| Access Control |
Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
| Management |
Access Control, Local Management, Remote Management |
| Protocols | Supports IPv4 |
| Guest Network | 2.4GHz guest network × 1, 5GHz guest network × 1 |
| OTHERS: | |
| Certification |
CE, FCC, RoHS |
| Package Contents |
TL-WR902AC, Power Adapter, USB Cable, Ethernet cable, Quick Installation Guide |
| System Requirements |
Microsoft® Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux |
| Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
| Standards |
IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2,4 GHz |
|---|---|
| Ports | 2 x 10/100/1000 Mb/s ports per Halo unit (WAN/LAN auto-sensing) |
| Button | 1 Reset button |
| Frequency range | 2.4 GHz and 5 GHz |
| Signal Rate |
400 Mbps on 2.4 GHz, 867 Mbps on 5 GHz |
| EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
| Wireless Security | WPA2-PSK + AES |
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
| Mesh protocol | 802.11k/v |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
| Management |
Access Control, Local Management, Remote Management |
| DHCP |
Server, Address Reservation, DHCP Client List |
| Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
| Protocols |
IPv4, IPv6 |
| Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
| Dimensions | 3.5 × 3.5 × 3.5 in (88 × 88 × 88 mm) |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
2 Halo H30G units, 2 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
| Standards |
IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2,4 GHz |
|---|---|
| Ports | 2 x 10/100/1000 Mb/s ports per Halo unit (WAN/LAN auto-sensing) |
| Button | 1 Reset button |
| Frequency range | 2.4 GHz and 5 GHz |
| Signal Rate |
400 Mbps on 2.4 GHz, 867 Mbps on 5 GHz |
| EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
| Wireless Security | WPA2-PSK + AES |
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
| Mesh protocol | 802.11k/v |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
| Management |
Access Control, Local Management, Remote Management |
| DHCP |
Server, Address Reservation, DHCP Client List |
| Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
| Protocols |
IPv4, IPv6 |
| Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
| Dimensions | 3.5 × 3.5 × 3.5 in (88 × 88 × 88 mm) |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
3 Halo H30G units, 3 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
Page 6 of 7
|
