Standards | IEEE 802.11b/g/n/ax |
---|---|
Interface | USB 2.0 |
Frequency range | 2.4GHz |
Max. speed | up to 2.4GHz 287Mbps |
Wireless Modes | Infrastructure mode |
Wireless Security |
WPA-PSK/WPA2-PSK, WPA/WPA2 |
Drivers | Supported operating systems include Windows 11/10 |
Dimmensions | 19,15 × 14,94 × 7,19 mm |
Standards | IEEE 802.11a/b/g/n/ac/ax |
---|---|
Interface | USB 2.0 |
Frequency range |
5GHz, 2.4GHz |
Max. speed | up to 5GHz 600Mbps or 2.4GHz 287Mbps |
Wireless Modes | Infrastructure mode |
Wireless Security |
WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK |
Drivers | Supported operating systems include Windows 11/10 |
Dimmensions | 19.2*15.7*7.4mm |
Operating temperatures | 0°C ÷ 40°C |
Operating humidity |
10% ÷ 90%, non-condensing |
Certificates |
CE, FCC, RoHS |
Manufacturer | TP-Link |
Standards | IEEE 802.11a/b/g/n/ac/ax |
---|---|
Interface | USB 2.0 |
Frequency range |
5GHz, 2.4GHz |
Antenna | 2× External 5 dBi High Gain Antennas |
Max. speed | up to 5GHz 1201Mbps or 2.4GHz 574Mbps |
Wireless Modes | Infrastructure mode |
Wireless Security |
WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK |
Drivers | Supported operating systems include Windows 11/10 |
Dimmensions | 26.8 × 15.7 × 7.5 mm (1.06 × 0.62 × 0.30 in) |
Operating temperatures | 0°C ÷ 40°C |
Operating humidity |
10% ÷ 90%, non-condensing |
Certificates |
CE, FCC, RoHS |
Manufacturer | TP-Link |
HARDWARE FEATURES: | |
---|---|
Interface | PCI Express x1 |
Antenna Type | Two High-Gain Dual Band Antennas |
Chipset | Intel Wi-Fi 6 Chipset |
WIRELESS FEATURES: | |
Wireless Standards |
5 GHz@ IEEE 802.11ax/ac/n/a, 2,4 GHz@ IEEE 802.11ax/n/g/b, Bluetooth 5.2 |
Frequency |
2.4-2.4835GHz, 5.180-5.240GHz, 5.745-5.825GHz |
Signal Rate |
1201Mbps at 5GHz, 574Mbps at 2.4GHz |
EIRP |
5 GHz @ 27 dBm (FCC) / 23 dBm (CE) (EIRP), 2,4 GHz @ 25 dBm (FCC) / 20 dBm (CE) (EIRP) |
Wireless Modes | Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
OTHERS: | |
Dimensions | 4.76 × 3.09 × 0.82 in (120.8 × 78.5 × 20.9 mm) |
Certification |
CE, FCC, RoHS, Wi-Fi |
Package Contents |
Archer TX20E, Two 5 dBi High Gain Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD |
System Requirements | Windows 10/11(64-bit) only |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
HARDWARE FEATURES: | |
---|---|
Interface | PCI Express x1 |
Antenna Type | Two High-Gain Dual Band Antennas |
Chipset | Intel Wi-Fi 6 Chipset |
WIRELESS FEATURES: | |
Wireless Standards |
5 GHz@ IEEE 802.11ax/ac/n/a, 2,4 GHz@ IEEE 802.11ax/n/g/b, Bluetooth 5.0/4.2/4.0 |
Frequency |
2.4-2.4835GHz, 5.180-5.240GHz, 5.745-5.825GHz |
Signal Rate |
2402Mbps at 5GHz, 574Mbps at 2.4GHz |
EIRP |
5 GHz @ 27 dBm (FCC) / 23 dBm (CE) (EIRP), 2,4 GHz @ 26 dBm (FCC) / 20 dBm (CE) (EIRP) |
Wireless Modes | Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
OTHERS: | |
Dimensions | 2,4 x 1,4 x 0,45 in (55 x 36 x 11,5 mm) |
Certification |
CE, FCC, RoHS, Wi-Fi |
Package Contents |
Archer TX55E, Two High Gain Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD |
System Requirements | Windows 10(64-bit) only |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
HARDWARE FEATURES: | |
---|---|
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
2 10/100/1000Mbps LAN Ports, 1 1G/100Mbps WAN Port |
Button | WPS/Reset Button |
Dimensions (W X D X H) | 6,9 × 6,2 × 1,8 in (175,6 × 157,2 × 45 mm) |
Antenna | 4× 5 dBi Fixed Omni-Directional Antennas |
WIRELESS FEATURES: | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 1201 Mbps (802.11ax), 2.4 GHz@ 400 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, WMM |
Wireless Security | WPA-PSK / WPA2-PSK/ WPA3 |
SOFTWARE FEATURES: | |
WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Management |
Access Control, Local Management, Remote Management |
DHCP |
Server, DHCP Client List |
NAT Forwarding |
Port Forwarding, Port Triggering, UPnP, DMZ |
Firewall Security |
SPI Firewall, IP and MAC Address Binding |
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
VPN Passthrough |
OpenVPN, PPTP supported |
OTHERS: | |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
HARDWARE FEATURES: | |
---|---|
Ports | 1 * 10/100/1000M Ethernet Port (RJ45) |
Plug Type | EU |
Button |
WPS Button, Reset Button |
Power Consumption | About 10W |
Wireless Standards |
IEEE802.11ax, IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Dimensions ( W x D x H ) | 84,7 × 39 × 112 mm |
Antenna Type | 2 x external |
WIRELESS FEATURES | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5GHz Up to 1201Mbps, 2.4GHz Up to 300Mpbs |
Wireless Security | WPA-PSK/WPA2-PSK |
OTHERS | |
Certification |
CE, RoHS |
Package Contents |
ME60X, Quick Installation Guide |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
HARDWARE FEATURES: | |
---|---|
Wireless Standards |
IEEE802.11ax, IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Dimensions ( W x D x H ) | 228 × 120.8 × 21.5 mm |
Antenna Type | 2× Fixed High-Performance Omni-Directional Antennas |
WIRELESS FEATURES | |
Frequency | 2.4GHz & 5GHz & 6GHz |
Signal Rate |
2402 Mbps on 6 GHz, 2402 Mbps on 5 GHz, 574 Mbps on 2.4 GHz |
Wireless Security | WPA-PSK/WPA2-PSK/WPA3-SAE |
OTHERS | |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
HARDWARE FEATURES: | |
---|---|
Interface | PCI Express x1 |
Antenna Type | Two High-Gain Dual Band Antennas |
Chipset | Intel Wi-Fi 6 Chipset |
WIRELESS FEATURES: | |
Wireless Standards |
5 GHz@ IEEE 802.11ax/ac/n/a, 2,4 GHz@ IEEE 802.11ax/n/g/b, Bluetooth 5.0/4.2/4.0 |
Frequency |
2.4-2.4835GHz, 5.180-5.240GHz, 5.745-5.825GHz |
Signal Rate |
2402Mbps at 5GHz, 574Mbps at 2.4GHz |
EIRP |
5 GHz @ 27 dBm (FCC) / 23 dBm (CE) (EIRP), 2,4 GHz @ 26 dBm (FCC) / 20 dBm (CE) (EIRP) |
Wireless Modes | Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
OTHERS: | |
Dimensions | 3.7 x 4.8 x 0.8 in (95.2 x 120.8 x 21.5 mm) |
Certification |
CE, FCC, RoHS, Wi-Fi |
Package Contents |
Archer TX50E, Two 5 dBi High Gain Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD |
System Requirements | Windows 10(64-bit) only |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
Standards |
IEEE 802.11ac, IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
---|---|
Interface | USB 3.0 |
Frequency range |
5GHz, 2.4GHz |
Antenna | 2× External 5 dBi High Gain Antennas |
Max. speed | up to 5GHz 1201Mbps or 2.4GHz 574Mbps |
Max. output power | 20 dBm |
Wireless Modes | Infrastructure mode |
Wireless Security |
WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
Drivers |
Supported operating systems include Windows 11/10, macOS |
Dimmensions | 84 × 156.3 × 19.2 mm (3.3 × 6.2 × 0.76 in) |
Operating temperatures | 0°C ÷ 40°C |
Operating humidity |
5% ÷ 90%, non-condensing |
Certificates |
CE, FCC, RoHS |
Manufacturer | TP-Link |
