| HARDWARE FEATURES: | |
|---|---|
| Interface |
1 10/100Mbps LAN/WAN Port, 3 10/100Mbps LAN Ports, 1 SIM Card Slot |
| Button |
WPS/Reset Button, Wireless On/Off Switch, Power On/Off Button |
| External Power Supply | 12VDC/1A |
| Dimensions ( W x D x H ) | 7.95 x 5.55 x 1.32 in. (202 x 141 x 33.6 mm) |
| Antenna Type |
2 Internal Wi-Fi Antennas, , 2 Detachable External 4G LTE Antennas |
| WIRELESS FEATURES: | |
| Wireless Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Frequency | 2.4GHz |
| EIRP | <20dBm |
| Signal Rate | 300Mbps at 2.4GHz |
| Wireless Security |
Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, Wireless MAC Filtering |
| SOFTWARE FEATURES: | |
| Security |
NAT Firewall, SPI Firewall, MAC / IP / Packet / Application / URL Filtering, Denial of Service(DoS), SYN Flooding, Ping of Death |
| Operating Modes |
3G/4G Router, Wireless Router |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Management |
Access Control, Local Management, Remote Management |
| DHCP |
Server, Client, DHCP Client List, Address Reservation |
| Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS |
DynDns, NO-IP |
| VPN Pass-Through |
PPTP, L2TP, IPSec |
| Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security |
DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding |
| Protocols | Supports IPv4 and IPv6 |
| Guest Network | 2.4GHz guest network x 1, 5GHz guest network x 1 |
| IPSec VPN | Supports up to 10 IPSec VPN tunnels |
| Network Type |
4G FDD-LTE Cat4 (800/900/1800/2100/2600MHz), TDD-LTE (2300/2600MHz), 3G DC-HSPA+/HSPA+/HSPA/UMTS (900/2100MHz), 2G EDGE/GPRS/GSM (850/900/1800/1900MHz) |
| OTHERS: | |
| Certification |
CE, FCC, RoHS |
| Package Contents |
3G/4G Wireless AC Router, 1 Antenna, RJ45 Ethernet Cable, Power Adapter, Quick Installation Guide, Micro to Standard SIM Card Adapter, Nano to Standard SIM Card Adapter |
| System Requirements |
Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
| Standards |
IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2,4 GHz |
|---|---|
| Ports | 2 LAN/WAN Gigabit Ethernet Ports |
| Processor | Quad-core CPU |
| Button | 1 Reset button on the underside |
| Flash | 32 MB |
| SDRAM | 256 MB |
| Bluetooth version | 4.2 and above |
| Frequency range | 2.4 GHz and 5 GHz |
| Signal Rate |
400 Mbps on 2.4 GHz, 867 Mbps on 5 GHz |
| EIRP |
FCC <30 dBm, CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
| Advanced Functions |
TP-Link Mesh Technology - MU-MIMO, Auto Path Selection, AP Steering, Band Steering, Beamforming |
| Wireless Security | WPA-PSK/WPA2-PSK |
| Software Features |
Quality of Service - WMM, IPv6 Support, WAN Type - Dynamic IP/Static IP/PPPoE, Local Management, Remote Management, DHCP - Server, Client, Port Forwarding Support, Access Control Blacklist, Firewall Security SPI Firewall, Protocols Supports IPv4 and IPv6, Homecare - Antivirus, Parental Controls, Quality of Service, Speedtest, Monthly Usage Reports, Auto FW Update, Expand for more deco, Guest Network 2.4 GHz guest network * 1 - 5 GHz guest network * 1, Beamformig, Easy setup by Deco App |
| Antenna | 4 internal antennas per Deco unit |
| Dimensions | Φ4.7 in. x 1.3 in. (Φ120 mm x 38 mm) |
| Power | 12 V/1.2 A |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
Deco unit, 1 RJ45 Ethernet Cable, Power Adapter |
| Smartphone/Tablet Requirements |
iOS 8.0 or later, Android 4.3 or later, Bluetooth 4.0 or later |
| Certificates |
CE, FCC, IC, NCC, BSMI, IDA |
| Ports |
3x 10/100/1000 Mbps RJ-45 (LAN), 1x RJ45 Serial Port |
|---|---|
| LEDs Per Data Port | Status/Power/Speed/Link/Activity |
| Processor |
Dual-Core 500 MHz, MIPS64 with Hardware Acceleration for Packet Processing |
| System Memory | 512 MB DDR2 RAM |
| On-Board Flash Storage | 2 GB |
| Layer 3 Forwarding Performance |
1,000,000 pps, 3 Gbps (Line Rate) |
| Max. Power Consumption | 7 W |
| Power |
12VDC, 1A Power Adapter (Included) |
| Power Input | 9 to 24VDC Supported Voltage Range |
| Dimensions | 135 x 135 x 28.3 mm (5.32 x 5.32 x 1.11") |
| Weight | 366 g |
| Operating temperatures | -10°C ÷ 45°C |
| Operating humidity |
10% ÷ 90%, non-condensing |
| Certificates |
CE, FCC, IC |
| Manufacturer | Ubiquiti |
| Standards |
IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2,4 GHz |
|---|---|
| Ports | 2 LAN/WAN Gigabit Ethernet Ports |
| Processor | Quad-core CPU |
| Button | 1 Reset button on the underside |
| Flash | 32 MB |
| SDRAM | 256 MB |
| Bluetooth version | 4.2 and above |
| Frequency range | 2.4 GHz and 5 GHz |
| Signal Rate |
400 Mbps on 2.4 GHz, 867 Mbps on 5 GHz |
| EIRP |
FCC <30 dBm, CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
| Advanced Functions |
TP-Link Mesh Technology - MU-MIMO, Auto Path Selection, AP Steering, Band Steering, Beamforming |
| Wireless Security | WPA-PSK/WPA2-PSK |
| Software Features |
Quality of Service - WMM, IPv6 Support, WAN Type - Dynamic IP/Static IP/PPPoE, Local Management, Remote Management, DHCP - Server, Client, Port Forwarding Support, Access Control Blacklist, Firewall Security SPI Firewall, Protocols Supports IPv4 and IPv6, Homecare - Antivirus, Parental Controls, Quality of Service, Speedtest, Monthly Usage Reports, Auto FW Update, Expand for more deco, Guest Network 2.4 GHz guest network * 1 - 5 GHz guest network * 1, Beamformig, Easy setup by Deco App |
| Antenna | 4 internal antennas per Deco unit |
| Dimensions | Φ4.7 in. x 1.3 in. (Φ120 mm x 38 mm) |
| Power | 12 V/1.2 A |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Package Contents |
3 Deco units, 1 RJ45 Ethernet Cable, 3 Power Adapters |
| Smartphone/Tablet Requirements |
iOS 8.0 or later, Android 4.3 or later, Bluetooth 4.0 or later |
| Certificates |
CE, FCC, IC, NCC, BSMI, IDA |
