19" Monitoring master unit (Sky Control 5500.824)

Compact device with dimensions 440×44×110, net weight 2kg. Supply includes: power supply 230V*12V, manual CD, warranty, technical data sheet, 3 plugs with terminal strip TBW-5-6P, 4 self-adhesive rubber legs.
Device is used for IP monitoring and remote management or as a video server in premises and site units, for example, in server rooms or telecommunication stations, detached buildings.
It is possible to connect up to 8 analog, 20 digital sensors, two 1-Wire Proximity Reader/I-touch button reader, 16 dry contacts and up to 4 relay devices.

Article	5500.824
TECHNICAL SPECIFICATIONS CONTROL
Installation	19" rack
IP monitoring	Web, SNMP, manual ICQ, SMS (GSM modem is ordered separately #08107)
Relay devices	Separate 3-level control of sensors and relay using login
INTERFACE & PROTOCOL SUPPORT
Interface	Access via any Internet browser, Flash support required
LAN	Ethernet 10/100Mbit
Network protocols	Built-in HTTP server, SNMP agent, SMTP agent, manageable logic. Uses FTP link for updating current software version
OS	Linux 2.6.23
RAM	32Mb
ROM 8Mb	FLASH
Software	Built-in software for events processing.
Alert type	eSMTP or SNMP traps, SMS, ICQ (GSM modem is ordered separately #08107)
LEDs	4 green PWR, ALRM, PRG (device reload through USB port), ACT
4 red	on/off relay outputs
PHYSICAL PARAMETERS
Power feed/ Voltage input	12V. In case of loss of adapter, any other chargers with minimum power of 10W can be used. Fuse protection.
Power consumption	6W
Max. power consumption	10W
Switching load per relay output	10A 250VAC or 10A 30V DC
Dimensions (LHW)	440×44×110mm
Net weight	2 kg
INLETS/OUTLETS
USB port	Webcam. Type most motion-jpeg cameras, image resolution 320×240, video is sent to email up to 320 Kb in one file (10-20secs).
Analog ports	8×6P6С for connection of various sensors. Fuse protection on each line.
Digital BUS	2×6P4С for connection of up to 20 digital sensors of humidity, voltage, motion or one access reader on each BUS. Fuse protection on each line.
Сontact control	16 dry contacts to control doors and window contacts, levels or voltage/power switches, etc.
Relay outputs	4 on/off x 230V*5A.
RS-485 port	1xRS-485 port of cascading for connection up to 30 extensional units
Manufacturer	Sky Control
