COMMUNICATION FOR INDUSTR.


COMMUNICATION FOR INDUSTRY » SERIAL DEVICE SERVERS » RS-XXX SERVERS WITH LAN (RJ-45 / FO) INTERFACE
Search for product:
#06574

Device server, 1x RS-232/422/485 + 1x 100 SM SC (LAN) (ORing IDS-5011FX-SS)

Physical Ports
100Base-FX Singlemode ports (30km, 1550nm, SC connector)
1
Serial Ports
Connector
DB9 x1
Operation Mode
RS-232,
RS-422,
RS-485 4/2-wire,
can be configured by DS-Tool
Serial Baud Rate
110 bps to 460.8 Kbps
Data Bits
5, 6, 7, 8
Parity
odd,
even,
none,
mark,
space
Stop Bits
1, 1.5, 2
RS-232
TxD,RxD,RTS,CTS,DTR,DSR,DCD,RI,GND
RS-422
Tx+,Tx-,Rx+,Rx-,GND
RS-485 (4-wire)
Tx+,Tx-,Rx+,Rx-,GND
RS-485 (2-wire)
Data+,Data-,GND
Flow Control
XON/XOFF,
RTS/CTS,
DTR/DSR
LED Indicators
Power indicator PWR 1(2) / Ready
Red On - Power is on and booting up,
Red Blinking - Indicates an IP conflict or DHCP or BOOTP server did not respond properly,
Green On - Power is on and functioning Normally,
Green Blinking - Located by Administrator
10/100TX RJ45 port indicator
Green for port Link/Act at 100Mbps,
Yellow for port Link/Act at 10Mbps
Fiber port indicator
Green for port Link/Act at 100Mbps
Serial TX / RX LEDs
Red - Serial port is receiving data,
Green - Serial port is transmitting data
Power
Input power
Dual DC inputs. 12÷48VDC on 3-pin terminal block
Power consumption (typical)
4W
Overload current protection
present
Reverse polarity protection
present on terminal block
Physical Characteristic
Enclosure
IP-30
Dimension (W x D x H)
72mm x 100mm x 31mm
Weight
325g
Environmental
Storage Temperature
-40÷85°C (-40÷185°F)
Operating Temperature
-10÷60°C (14÷140°F)
Operating Humidity
5%÷95% Non-condensing
Regulatory approvals
EMI
FCC Part 15,
CISPR (EN55022) class A
EMS
EN61000-4-2 (ESD),
EN61000-4-3 (RS),
EN61000-4-4 (EFT),
EN61000-4-5 (Surge),
EN61000-4-6 (CS),
EN61000-4-8,
EN61000-4-11
Shock
IEC60068-2-27
Free Fall
IEC60068-2-32
Vibration
IEC60068-2-6
Safety
EN60950
Warranty
Warranty period
5 years
Print to PDF
Technical Support
ORING
Net Price: 211,00 196,00 EUR  Unit: pcs
Minimal order quantity: 1 x pcs
Quantity in the smallest collective package: 1 x pcs
x pcs
[+]add item to comparison | show comparison [0]
Documentation:
Manual (2,65 MB)
Technical specification (331 KB)
