Unmanaged switch, 8x 10/100 RJ-45 (ORing IES-1080)

IES-1000 Series are designed for industrial-grade Ethernet, and particularly for facilities of rugged industry and infrastructure. These switches are tailored to perform various features, such as wide temperature, redundant power input (8-port models), relay output alarm, surge protectionKetc. The 8-port models of IES-1000 Series offer three different power inputs to enhance its reliability, two supplied by terminal block, and one by power jack. When the primary DC power input fails, the backup power input will take over immediately to guarantee a non-stop operation. Thus, the IES-1000 Series is the best choice for facility management, sewage treatment, power utility, telecommunication, transportation and all other mission-critical applications that require reliable Ethernet connectivity.

Physical Ports
10/100 Base-T(X) Ports in RJ45 Auto MDI/MDIX	8
Technology
Ethernet Standards	IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X), IEEE 802.3x for Flow control
MAC Table	8192 MAC addresses
Processing	Store-and-Forward
Software Features	Port configuration, Port status, Port statistics, Port monitoring, Port security
LED Indicators
Power indicator	Green - Power LED x 3
Fault indicator	Yellow - Indicate PWR1 or PWR2 failure
10/100TX RJ45 port indicator	Green for port Link/Act, Yellow for Duplex/Collision
Fault contact
Relay	Relay output to carry capacity of 1A at 24VDC
Power
Input power	Triple DC inputs. 12÷48VDC on 7-pin terminal block, 12÷45VDC on power jack
Power consumption (typical)	4W
Overload current protection	present
Reverse polarity protection	present on terminal block
Physical Characteristic
Enclosure	IP-30
Dimension (W x D x H)	52mm x 106mm x 144mm
Weight	666g
Environmental
Storage Temperature	-40÷85°C(-40÷185°F)
Operating Temperature	-40÷70°C (-40÷158°F)
Operating Humidity	5%÷95% Non-condensing
Regulatory approvals
EMI	FCC Part 15, CISPR (EN55022) class A
EMS	EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11
Shock	IEC60068-2-27
Free Fall	IEC60068-2-32
Vibration	IEC60068-2-6
Safety	EN60950
Warranty
Warranty period	5 years
